DESCRIPTION
This turbocharger is a key component for enhancing engine power and efficiency, designed to meet Cummins' rigorous standards. It ensures optimal air flow into the combustion chamber, boosting engine performance and fuel efficiency. Its precision engineering and quality construction make it a dependable upgrade or replacement part for improving engine capabilities.
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| Rectangular Ring Seal | 1 | 3502449 |
| Plain Washer | 4 | 3504967 |
| Drive Screw | 2 | 3519163 |
| Retaining Ring | 4 | 3519641 |
| Hexagon Head Set Screw | 8 | 3521225 |
| Split Ring Seal | 1 | 3521442 |
| Roll Pin | 2 | 3522597 |
| Lockplate | 4 | 3522904 |
| Split Ring Seal | 1 | 3523412 |
| Shim | 1 | 3524418 |
| Oil Baffle | 1 | 3524419 |
| Rectangular Ring Seal | 1 | 3534405 |
| Turbocharger Heat Shield | 1 | 3535611 |
| Turbocharger Thrust Bearing | 1 | 3536914 |
| Retaining Ring | 1 | 3537301 |
| Turbocharger Noise Baffle | 1 | 3537916 |
| Socket Head Cap Screw | 4 | 3590377 |
| v Band Clamp | 1 | 3590386 |
| Socket Head Cap Screw | 1 | 3590435 |
| Lock Nut | 1 | 3590444 |
| Mounting Spacer | 1 | 3590445 |
| Thrust Collar | 1 | 3591522 |
| Compressor Housing | 1 | 3594369 |
| Shaft Wheel Rotor | 1 | 3595589 |
| Turbocharger Bearing | 2 | 3598528 |
| Lock Nut | 1 | 3771005 |
| Oil Slinger | 1 | 4036307 |
| Turbine Housing | 1 | 4036569 |
| Turbocharger Diffuser | 1 | 4039608 |
| Turbocharger Bearing Housing | 1 | 4043801 |
| Turbocharger Compressor Impeller | 1 | 5323935 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
* Variable geometry turbocharger and electronic actuator repairs are not eligible to be claimed as over-the-counter under New or ReCon parts warranty for parts installed after October 1, 2018.
* Diesel Oxidation Catalyst (DOC), Diesel Particulate Filter (DPF), Selective Catalyst Reduction (SCR) catalyst, and Electronic Control Module (ECM) repairs are not eligible to be claimed as over-the-counter under New or ReCon parts warranty for parts installed after January 1, 2020.
* These restrictions are only applicable to New parts and ReCon parts coverages for the components listed above sold to a customer in the US or Canada. All other coverages are excluded. All other regions are excluded.
* Variable geometry turbocharger and electronic actuator repairs are not eligible to be claimed as over-the-counter under New or ReCon parts warranty for parts installed after October 1, 2018.
* Diesel Oxidation Catalyst (DOC), Diesel Particulate Filter (DPF), Selective Catalyst Reduction (SCR) catalyst, and Electronic Control Module (ECM) repairs are not eligible to be claimed as over-the-counter under New or ReCon parts warranty for parts installed after January 1, 2020.
* These restrictions are only applicable to New parts and ReCon parts coverages for the components listed above sold to a customer in the US or Canada. All other coverages are excluded. All other regions are excluded.
