ETN0513689
S130FLR Differential Rear 4.88
Dana Spicer
DISCONTINUED
This truck part is made by Dana Spicer. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
DIFFERENTIAL REAR S130FLR 4.88
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| NUT PIN BEARING CAGE CHECK | 1 | ETN0130542 |
| CARRIER, DIFFERENTIAL W/BEARING CAPS | 1 | DS511860 |
| CARRIER, DIFFERENTIAL W/BEARING CAPS | 1 | ETN0511860 |
| BOLT, DIFFERENTIAL CARRIER BEARING CAP | 6 | DS130596 |
| BOLT, DIFFERENTIAL CARRIER BEARING CAP | 6 | ETN0130596 |
| WASHER BOLT COVER | 6 | DS128415HX |
| WASHER BOLT COVER | 6 | ETN0128415 |
| SWITCH, SENSOR ANTILOCK BRAKE SYSTEM (ABS) (ANTILOCK BRAKE SYSTEM (ABS)) S110/130 | 1 | ETN2006251 |
| BOLT, SWITCH | 1 | DS486721 |
| BOLT, SWITCH | 1 | ETN0486721 |
| RING ANTILOCK BRAKE SYSTEM (ABS) (ANTILOCK BRAKE SYSTEM (ABS)) EXCITER | 1 | ETN0130602 |
| BOLT, GEAR | 10 | ETN0132820 |
| CUP, BEARING | 1 | FP3984 |
| CUP, BEARING | 1 | FP3920 |
| ADJUSTER DIFFERENTIAL BEARING LEFT /RIGHT 14ADP | 1 | 1697161C1 |
| CASE, DIFFERENTIAL PLAIN HALF S130 | 1 | ETN0130769 |
| PLUG, FILL DIFFERENTIAL | 1 | ETN0054254 |
| WASHER, THRUST DIFFERENTIAL SPIDER GEAR | 4 | ETN0129305 |
| GEAR, PINION DIFFERENTIAL | 4 | DS133761 |
| GEAR, PINION DIFFERENTIAL | 4 | ETN0127364 |
| GEAR, DIFFERENTIAL SIDE S130 | 2 | ETN0132807 |
| PIN, DOWEL | 2 | ETN0130605 |
| PIN, SHAFT DIFFERENTIAL S130 | 2 | ETN0130768 |
| PIN, SHAFT DIFFERENTIAL S130 | 1 | ETN0130767 |
| PIN, DOWEL | 2 | ETN0132821 |
| SEAL, OIL PINION AND INNER SHAFT | 1 | DS127591 |
| SEAL, OIL PINION AND INNER SHAFT | 1 | ETN0127591 |
| WASHER, THRUST DIFFERENTIAL SIDE GEAR | 1 | ETN0127386 |
| DIFFERENTIAL ASSEMBLY, REAR RATIO TRUETAC NO SPIN S130 | 1 | ETN0513305 |
| BEARING | 1 | FP55200C |
| BEARING | 1 | ETN0012496 |
| CUP, BEARING PINION | 1 | FP55437 |
| BEARING, CUP PINION | 1 | FP72487 |
| BEARING, CONE PINION CAGE | 1 | DS129562 |
| BEARING, CONE PINION CAGE | 1 | ETN0129562 |
| KIT, DIFFERENTIAL BEARING AND SEAL | 1 | DS504070 |
| KIT, DIFFERENTIAL BEARING AND SEAL | 1 | ETN0511859 |
| DIFFERENTIAL KIT, WHEEL WITH SIDE GEAR S130 | 1 | ETN0514374 |
| DIFFERENTIAL KIT, WHEEL LEFT SIDE GEAR S130 | 1 | DS514373 |
| DIFFERENTIAL KIT, WHEEL LEFT SIDE GEAR S130 | 1 | ETN0514373 |
| SPACER KIT, BEARING | 1 | ETN0504039 |
| GEAR SET R&P 4.88 KIT | 1 | ETN0513978 |
