4085820C92
SEAT, DRIVER, HP3 AIR SUSPENSION, MORDURA, FEDEX LOGO
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$1,549.95
$1,859.94
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
RELATED PARTS
SPECIFICATIONS
OEM Description
SEAT, DRIVER, HP3 AIR SUSPENSION, MORDURA, FEDEX LOGO
Weight
96.8 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| UPHOLSTERED CUSHION | 1 | 2516464C91 |
| TRACK KIT | 1 | 2516468C91 |
| VALVE, CONTROL LUMBAR | 1 | 2600683C1 |
| UPHOLSTERED BACK | 1 | 2516465C91 |
| FEDEX BACK COVER | 1 | NS23094257 |
| MOUNTING PLATE, SEAT BASE TO FLOOR | 1 | 2516472C91 |
| REST ARM RIGHT HAND | 1 | 2606875C1 |
| LOWER CUSHION /FR | 1 | 2516470C1 |
| SWITCH, LUMBAR CYCLER, SEAT SENSOR | 1 | 2594768C1 |
| COVER ARM CHAR MRD RH | 1 | NS235065132 |
| LH AR CVR, CHARCOAL MORDURA | 1 | NS235065131 |
| PRESSURE PROTECTION VALVE | 1 | 2516471C1 |
| VALVE, LOW PRESSURE AIR GRAY HANDLE | 1 | 2505476C1 |
| REST, ARM LH | 1 | 2607773C1 |
| REST, ARM LH | 1 | 2606874C1 |
| VALVE, HIGH PRESSURE AIR RED HANDLE | 1 | 2505475C1 |
| PEDESTAL SEAT | 1 | 2516469C91 |
| FR, BACK FR | 1 | 2515948C1 |
| SUPPORT, ASSEMBLY SEAT AIR LIMBAR | 1 | 2509416C91 |
| SUPPORT ASSEMBLY AIR LUMBAR | 1 | 2594761C1 |
| SUPPORT, ASSEMBLY SEAT AIR LIMBAR | 1 | 1699520C1 |
| SHOCK ABSORBER KIT | 1 | 2512928C1 |
| FEDEX CUSHION COVER | 1 | NS23094323 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
