3765598C95
PANEL, DOOR ASSEMBLY, LEVEL 2, ALL POWER, LEFT HAND
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$309.95
$371.94
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
RELATED PARTS
SPECIFICATIONS
OEM Description
PANEL, DOOR ASSEMBLY, LEVEL 2, ALL POWER, LEFT HAND
Weight
15 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| PANEL, FULL, DOOR TRIM, ALL POWER, W/LAMP, LEFT HAND | 1 | 3765616C2 |
| SCREW, M5 X 14MM | 6 | 3768429C1 |
| BUSHING, COMPRESSION LIMITER | 6 | 3765643C1 |
| PANEL, LEVEL 2 BOLSTER ASSEMBLY, LEFT HAND | 1 | 3765637C1 |
| FASTENER, DOOR TRIM RETAINER | 6 | 3805943C1 |
| PANEL, MAP POCKET CLOSEOUT, LEFT HAND | 1 | 6126373C2 |
| PANEL, LOCK ROD GROMMET, LEFT HAND | 1 | 6126375C2 |
| SEAL PVC FOAM, 1/8"THK X 1" WIDE X 1 FT LG/BLACK | 2 | 453761C1 |
| HANDLE, DOOR INSIDE, CHROME, LEFT HAND | 1 | 4053965C92 |
| HANDLE, GRAB, BASE, LEFT HAND | 1 | 6126377C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
