ETN0675941
DIFFERENTIAL 4.88:1
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$3,099.95
$3,719.94
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
RELATED PARTS
SPECIFICATIONS
VMRS
027-015-000
OEM Description
DIFFERENTIAL-4.88 17/19/21060S
Weight
293.61 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| SPACER, PINION BEARING .623" | 1 | ZBP0091552 |
| SPACER, PINION BEARING .623" | 1 | ETN0091552 |
| WASHER, THRUST DIFFERENTIAL SIDE GEAR | 2 | ETN0127386 |
| BOLT, DIFFERENTIAL CASE | 12 | ETN0127465 |
| BOLT, CASE DIFF | 16 | 2515108C91 |
| BEARING CONE /ROLLERS | 1 | ETN0134306 |
| BEARING CUP | 1 | ETN0134301 |
| CASE DIFFERENTIAL FLANGE HALF D/R404 | 1 | ETN0133739 |
| WASHER, THRUST DIFFERENTIAL SPIDER GEAR | 4 | ETN0129305 |
| " GEAR, PINION " | 4 | DS133761 |
| " GEAR, PINION " | 4 | ETN0133761 |
| SEAL, OIL PINION AND INNER SHAFT | 1 | DS127591 |
| SEAL, OIL PINION AND INNER SHAFT | 1 | ETN0127591 |
| CASE DIFFERENTIAL PLN HALF STANDARD S/RS404 | 1 | ETN0132437 |
| CAGE AND CUP ASSEMBLY | 1 | DS10003017 |
| ASSEMBLY, WHEEL DIFFERENTIAL | 1 | ETN0217280 |
| SPIDER, DIFFERENTIAL | 1 | ETN0127359 |
| NUT, MOUNTING COMPANION FLANGE M36 X 1.5-4H | 1 | ETN0127589 |
| SHIM, CAGE INPUT SHAFT .01" | 1 | ETN0127597 |
| BEARING CONE /ROLLERS | 1 | ETN0134308 |
| BEARING CUP | 1 | ETN0134298 |
| BOLT, PINION BEARING CAGE | 6 | DS210115 |
| BOLT, PINION BEARING CAGE | 6 | ETN0210115 |
| PIN, COTTER | 1 | ETN0090873 |
| CARRIER CAPS ASSEMBLY | 1 | ETN0127603 |
| BEARING, PINION PILOT | 1 | 2518855C91 |
| CUP, BEARING INNER | 1 | ETN0134292 |
| NUT, BOLT DIFFERENTIAL CASE | 16 | ETN0126216 |
| BEARING CONE /ROLLERS | 1 | ETN0134300 |
| GEAR, SIDE DIFFERENTIAL 39 SPLINE | 2 | ETN0127367 |
| CUP, BEARING OUTER | 1 | ETN0134295 |
| BEARING CONE /ROLLERS | 1 | ETN0134297 |
CROSS REFERENCES
- DANA 0675941
- DANA 0675941
- DANA 675941
- DANA 675941
