ETN0515374
DIFFERENTIAL F/R DS404 3.42
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$3,699.95
$4,439.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
DIFFERENTIAL F/R DS404 3.42
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| GEAR, HELICAL DRIVE DIFFERENTIAL | 1 | ETN0127523 |
| CUP, BEARING DIFFERENTIAL | 1 | DS134298 |
| CUP, BEARING DIFFERENTIAL | 1 | ETN0129564 |
| BEARING, CONE DIFFERENTIAL | 1 | DS134297 |
| BEARING, CONE DIFFERENTIAL | 1 | ETN0129563 |
| CASE, DIFFERENTIAL 3.36-3.90 RATIO | 1 | ETN0508654 |
| CASE DIFFERENTIAL PLN HALF STANDARD S/RS404 | 1 | ETN0132437 |
| BOLT, DIFFERENTIAL CASE | 12 | ETN0127465 |
| GEAR, SIDE DIFFERENTIAL 41 SPLINE | 2 | ETN0127368 |
| WASHER, THRUST DIFFERENTIAL SIDE GEAR | 2 | ETN0127386 |
| WASHER, THRUST DIFFERENTIAL SPIDER GEAR | 4 | ETN0129305 |
| GEAR, PINION DIFFERENTIAL | 4 | DS133761 |
| GEAR, PINION DIFFERENTIAL | 4 | ETN0127364 |
| SPIDER, DIFFERENTIAL | 1 | ETN0127359 |
| PIN, SPRING WINDING LEVER | 1 | ETN0118807 |
| NUT, BOLT DIFFERENTIAL CASE | 16 | ETN0126216 |
| BOLT, DIFFERENTIAL CASE | 16 | ETN0129686 |
| BEARING, ROLLER PILOT PINION | 1 | ETN0127484 |
| BEARING, CONE PINION | 1 | DS134291 |
| BEARING, CONE PINION | 1 | ETN0129560 |
| CARRIER, DIFFERENTIAL PINION GEAR W/CUPS | 1 | ETN0129767 |
| CUP, BEARING PINION CAGE | 1 | ETN0129561 |
| BEARING | 1 | DS012495 |
| BEARING | 1 | ETN0012495 |
| BEARING- CONE PIN CAGE INNER /OTR | 1 | ETN0127535 |
| BOLT, PINION BEARING CAGE | 6 | DS210115 |
| NUT PINION SHAFT | 1 | ETN0126182 |
| CLUTCH, SLIDING INTERMEDIATE AXLE DIFFERENTIAL | 1 | ETN0127510 |
| GEAR DIFFERENTIAL HELICAL WITH BUSHING | 1 | ETN0130907 |
| WASHER, HELICAL GEAR | 1 | ETN0128702 |
| SPRING, COMPRESSION | 1 | DS129859 |
| SPRING, COMPRESSION | 1 | ETN0129859 |
| GEAR SET-F/R R/P 3.42 14GEP/R | 1 | ETN0504056 |
| BEARING | 1 | ETN0110811 |
| GEAR, SIDE INTERMEDIATE AXLE DIFFERENTIAL REAR | 1 | DS10026797 |
| GEAR, SIDE INTERMEDIATE AXLE DIFFERENTIAL REAR | 1 | ETN0127645 |
| RING, SNAP | 1 | DS085997 |
| RING, SNAP | 1 | ETN0085997 |
| O-RING | 1 | ETN0131809 |
| RETAINER, INPUT SHAFT BEARING REAR | 1 | ETN0128700 |
| PIN, COTTER | 2 | ETN0090873 |
| SHAFT, INPUT WITHOUT CONE BEARING | 1 | DS134303 |
| SHAFT, INPUT WITHOUT CONE BEARING | 1 | ETN0129558 |
| CLUTCH, CURVIC GEAR FIXED | 1 | ETN0128627 |
| RING, SNAP CURVIC CLUTCH | 1 | ETN0129433 |
| GEAR, SLIDING CURVIC CLUTCH DIFFERENTIAL | 1 | ETN0126840 |
| SPRING, COMPRESSION SHIFT FORK | 1 | ETN0128614 |
| PIN, ROLLER DIFFERENTIAL SHIFT FORK | 1 | ETN0210020 |
| COVER, INTERMEDIATE AXLE DIFFERENTIAL | 1 | ETN0130823 |
| WASHER BOLT COVER | 11 | DS128415HX |
| WASHER BOLT COVER | 11 | ETN0128415 |
| BOLT, DIFFERENTIAL CASE | 11 | ETN0210091 |
| SEAL, "V" RING INPUT SHAFT BEARING POWER DIVIDER LOCK | 1 | ETN0128703 |
| PIN, DOWEL CARRIER BEARING CAP | 2 | ETN0007641 |
| CUP, BEARING INPUT SHAFT | 1 | 2517663C91 |
| CUP, BEARING INPUT SHAFT | 1 | ETN1008912 |
| CARRIER, DIFFERENTIAL INPUT SHAFT POWER DIVIDER LOCK | 1 | ETN0129575 |
| BOLT, PINION BEARING CAGE | 6 | ETN0210115 |
| SEAL, OIL PINION AND INNER SHAFT | 1 | DS127591 |
| SEAL, OIL PINION AND INNER SHAFT | 1 | ETN0127591 |
| O-RING COVER | 1 | ETN0129576 |
| TROUGH, LUBE | 1 | ETN0129577 |
| YOKE, SHIFT W/SPRING | 1 | ETN0510870 |
| NUT DIFFERENTIAL PINION GEAR BEARING | 1 | ETN0128049 |
| CAP, PISTON | 1 | ETN0129573 |
| ADJUSTER DIFFERENTIAL BEARING | 1 | ETN0129130 |
| ROD, SHIFT FORK PUSH DIFFERENTIAL LOCK | 1 | ETN0128617 |
| DRIVER, PISTON | 1 | DS132489 |
| DRIVER, PISTON | 1 | ETN0128640 |
| SCREW, SET SHIFT FORK | 1 | ETN0128618 |
| PISTON, AIR SHIFT CYLINDER | 1 | ETN0128624 |
| O-RING PISTON | 1 | ETN0210180 |
| WASHER NYLON SWITCH | 1 | ETN0129034 |
| SWITCH, DIFFERENTIAL LOCK INDICATOR | 1 | ETN0129035 |
| CUP, BEARING DIFFERENTIAL | 1 | DS134301 |
| CUP, BEARING DIFFERENTIAL | 1 | ETN0129566 |
| BEARING, CONE DIFFERENTIAL | 1 | DS134300 |
| BEARING, CONE DIFFERENTIAL | 1 | ETN0129565 |
| PLUG- DRAIN PDV CASE | 1 | 9409949 |
| PLUG- DRAIN PDV CASE | 1 | ETN0090325 |
| WASHER, THRUST INPUT DS404 | 1 | ETN0132439 |
| CARRIER, DIFFERENTIAL INPUT SHAFT | 1 | ETN0127602 |
| BEARING- CONE D404 | 1 | ETN0132060 |
| ADJUSTER DIFFERENTIAL BEARING LEFT OR RIGHT | 1 | ETN0129128 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
