ETN0512067
DIFFERENTIAL-RR 4.33 23105D 36
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$7,699.95
$9,239.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
DIFFERENTIAL RR CT 4.33 14AEL
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| WASHER NYLON SWITCH | 1 | ETN0129034 |
| SWITCH, DIFFERENTIAL LOCK INDICATOR | 1 | ETN0129035 |
| ADJUSTER DIFFERENTIAL BEARING RIGHT | 1 | ETN0113885 |
| BEARING CUP | 1 | TMJM822010 |
| BEARING CUP | 1 | ETN0083824 |
| BEARING | 1 | ETN0083825 |
| ADJUSTER DIFFERENTIAL BEARING LEFT | 1 | ETN0126729 |
| CUP, BEARING DIFFERENTIAL | 1 | ETN0126924 |
| BEARING, CONE DIFFERENTIAL | 1 | FP56425 |
| BEARING, CONE DIFFERENTIAL | 1 | ETN0027817 |
| WASHER- CARRIER BEARING CAP BOLT OR ST | 4 | ETN0032912 |
| BOLT | 12 | ETN0088503 |
| GEAR, SIDE DIFFERENTIAL | 2 | ETN0093401 |
| WASHER, THRUST DIFFERENTIAL SIDE GEAR | 2 | ETN0027274 |
| WASHER, THRUST DIFFERENTIAL SPIDER GEAR | 4 | ETN0086781 |
| GEAR, SPIDER DIFFERENTIAL | 4 | ETN0086780 |
| SPIDER, DIFFERENTIAL | 1 | ETN0086778 |
| NUT | 16 | ETN0084497 |
| BOLT | 16 | ETN0113888 |
| BEARING, PILOT PINION GEAR | 1 | ETN0120080 |
| BEARING, CONE PINION | 1 | ETN0126286 |
| BOLT, BEARING CAP | 2 | ETN0127180 |
| CUP, BEARING PINION | 1 | ETN0126287 |
| CARRIER, DIFFERENTIAL PINION GEAR W/CUPS | 1 | ETN0126290 |
| BOLT | 6 | ETN0113867 |
| BEARING CUP PINION OUTER | 1 | FPHM813810 |
| BEARING CUP PINION OUTER | 1 | ETN0113869 |
| BEARING CONE PINION OUTER | 1 | TMHM813841 |
| BEARING CONE PINION OUTER | 1 | ETN0113868 |
| WASHER, SPACER COMPRESSION FLANGE | 1 | ETN0126940 |
| SEAL, OIL PINION GEAR | 1 | ETN0210724 |
| LOCK, DIFFERENTIAL BEARING ADJUSTER | 1 | ETN0126979 |
| CLUTCH, FIXED DIFFERENTIAL | 1 | ETN0127810 |
| RING, SNAP FIXED CURVIC CLUTCH | 1 | ETN0126728 |
| CLUTCH, SLIDING DIFFERENTIAL | 1 | ETN0129263 |
| SPRING, AXLE SHIFT PUSH ROD | 1 | ETN0031038 |
| GUIDE, ACTUATOR SWITCH | 1 | ETN0210279 |
| YOKE, SHIFT DIFFERENTIAL LOCK W/PINS | 1 | ETN0219457 |
| PIN, ROLLER DIFFERENTIAL SHIFT FORK | 1 | ETN0210020 |
| BOLT, SHIFT FORK ADJUSTING | 1 | ETN0210191 |
| PIN- COTTER | 2 | ETN0090876 |
| ROD, PUSH SHIFT CYLINDER | 1 | ETN0210277 |
| PISTON, SHIFT COVER | 1 | ETN0129290 |
| O-RING PISTON | 1 | ETN0210180 |
| GASKET PISTON COVER | 1 | DS128643 |
| GASKET PISTON COVER | 1 | ETN0128643 |
| BOLT, SHIFT CYLINDER MOUNTING | 2 | ETN0128744 |
| CYLINDER DIFFERENTIAL SHIFT LOCK | 1 | ETN0511776 |
| LOCK, DIFFERENTIAL BEARING ADJUSTER RIGHT | 1 | ZBP0014275 |
| LOCK, DIFFERENTIAL BEARING ADJUSTER RIGHT | 1 | ETN0014275 |
| BOLT, ADJUSTING DRIVE GEAR THRUST | 1 | ETN0126193 |
| NUT DRIVE GEAR ADJUSTABLE SCREW | 1 | ETN0210184 |
| SCREW, SET | 1 | DS129946 |
| SCREW, SET | 1 | ETN0129946 |
| PLUG, PISTON COVER SIDE PORT | 1 | ETN0127195 |
| PLUG- DRAIN PDV CASE | 1 | 9409949 |
| PLUG- DRAIN PDV CASE | 1 | ETN0090325 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
