ETN0512052
DIFFERENTIAL REAR 6.50 NS ANTILOCK BRAKE SYSTEM (ABS) (ANTILOCK BRAKE SYSTEM (ABS))
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$3,599.95
$4,319.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
VMRS
027-015-000
OEM Description
DIFFERENTIAL REAR 6.50 NS ANTILOCK BRAKE SYSTEM (ABS) (ANTILOCK BRAKE SYSTEM (ABS))
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| CARRIER, DIFFERENTIAL W/BEARING CAPS | 1 | ETN0510018 |
| BEARING, CONE DIFFERENTIAL | 1 | DS134297 |
| BEARING, CONE DIFFERENTIAL | 1 | ETN0129563 |
| CASE, DIFFERENTIAL 5.29-7.17 RATIO | 1 | ETN0508656 |
| BOLT, DIFFERENTIAL CASE | 12 | ETN0127465 |
| GEAR, SIDE DIFFERENTIAL 41 SPLINE | 2 | ETN0127368 |
| WASHER, THRUST DIFFERENTIAL SIDE GEAR | 2 | ETN0127386 |
| WASHER, THRUST DIFFERENTIAL SPIDER GEAR | 4 | ETN0129305 |
| GEAR, PINION DIFFERENTIAL | 4 | DS133784 |
| GEAR, PINION DIFFERENTIAL | 4 | ETN0129765 |
| SPIDER, DIFFERENTIAL | 1 | ETN0129599 |
| NUT, BOLT DIFFERENTIAL CASE | 16 | ETN0126216 |
| WASHER, BOLT CARRIER BEARING CAP | 4 | ETN0210288 |
| BOLT, DIFFERENTIAL CASE | 16 | ETN0129686 |
| BEARING, ROLLER PILOT PINION | 1 | ETN0127485 |
| BEARING, CONE PINION CAGE | 1 | DS129562 |
| BEARING, CONE PINION CAGE | 1 | ETN0129562 |
| CARRIER, DIFFERENTIAL PINION GEAR W/CUPS | 1 | ETN0129768 |
| CUP, BEARING PINION CAGE | 1 | ETN0129561 |
| BEARING | 1 | DS012495 |
| BEARING | 1 | ETN0012495 |
| BEARING | 1 | FP55200C |
| BEARING | 1 | ETN0012496 |
| BOLT, PINION BEARING CAGE | 6 | DS210115 |
| BOLT, PINION BEARING CAGE | 6 | ETN0210115 |
| BOLT, DIFFERENTIAL CARRIER BEARING CAP | 4 | ETN0210095 |
| SEAL, OIL PINION AND INNER SHAFT | 1 | DS127591 |
| SEAL, OIL PINION AND INNER SHAFT | 1 | ETN0127591 |
| NUT, MOUNTING COMPANION FLANGE M36 X 1.5-4H | 1 | ETN0127589 |
| BOLT, ADJUSTING DRIVE GEAR THRUST | 1 | ETN0126193 |
| NUT DRIVE GEAR ADJUSTABLE SCREW | 1 | ETN0210184 |
| O-RING | 1 | ETN0131809 |
| GEAR SET, SIDE AND PINION DIFFERENTIAL | 1 | ETN0510397 |
| PIN, COTTER | 2 | ETN0090873 |
| ADJUSTER DIFFERENTIAL BEARING | 1 | ETN0129130 |
| CUP, BEARING DIFFERENTIAL | 1 | DS134301 |
| CUP, BEARING DIFFERENTIAL | 1 | ETN0129566 |
| ADJUSTER DIFFERENTIAL BEARING LEFT OR RIGHT | 1 | ETN0129128 |
| DIFFERENTIAL ASSEMBLY NO SPIN | 1 | ETN0128776 |
| CUP, BEARING DIFFERENTIAL | 1 | DS134298 |
| CUP, BEARING DIFFERENTIAL | 1 | ETN0129564 |
CROSS REFERENCES
- DANA 0512052
- DANA 0512052
- DANA 512052
- DANA 512052
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
