ETN0511910
DIFFERENTIAL-RR CT 2.85 23085D
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$4,899.95
$5,879.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
DIFFERENTIAL, REAR CT 2.85 14AGJ
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| NUT DRIVE GEAR ADJUSTABLE SCREW | 1 | ETN0210184 |
| BEARING CUP PINION OUTER | 1 | FPHM813810 |
| BEARING CUP PINION OUTER | 1 | ETN0113869 |
| BOLT, PINION GEAR BEARING RETAINER | 6 | ETN0210094 |
| CARRIER, DIFFERENTIAL PINION GEAR W/CUPS | 1 | ETN0129854 |
| CUP, BEARING PINION | 1 | ETN0129848 |
| WASHER NYLON SWITCH | 1 | ETN0129034 |
| BEARING, CONE PINION | 1 | ETN0129847 |
| BEARING PINION REAR /REAR | 1 | ETN0129947 |
| ADJUSTER DIFFERENTIAL BEARING RIGHT | 1 | ETN0210179 |
| CUP, BEARING DIFFERENTIAL | 1 | DS134301 |
| CUP, BEARING DIFFERENTIAL | 1 | ETN0129566 |
| BOLT, ADJUSTING DRIVE GEAR THRUST | 1 | ETN0126193 |
| BEARING, CONE DIFFERENTIAL | 1 | DS134300 |
| BEARING, CONE DIFFERENTIAL | 1 | ETN0129565 |
| BOLT, DIFFERENTIAL CASE | 12 | ETN0210513 |
| PIN, COTTER | 2 | ETN0090873 |
| BOLT, DIFFERENTIAL CARRIER BEARING CAP | 4 | ETN0210095 |
| WASHER, BOLT CARRIER BEARING CAP | 4 | ETN0210288 |
| WASHER, THRUST DIFFERENTIAL SIDE GEAR | 2 | ETN0083726 |
| GEAR- DIFFERENTIAL SIDE | 2 | ETN0118959 |
| WASHER, THRUST SIDE PINION GEAR | 4 | ETN0108145 |
| GEAR, SIDE PINION | 4 | ETN0108142 |
| SPIDER, DIFFERENTIAL | 1 | ETN0108141 |
| PLUG- DRAIN PDV CASE | 1 | 9409949 |
| PLUG- DRAIN PDV CASE | 1 | ETN0090325 |
| BOLT, DIFFERENTIAL DRIVE GEAR | 16 | ETN0126221 |
| GEAR SET, SIDE AND PINION DIFFERENTIAL | 1 | ETN0121785 |
| GEAR SET, RING AND PINION DIFFERENTIAL 2.85:1 | 1 | ETN0214542 |
| NUT, HEXAGON DIFFERENTIAL DRIVE GEAR BOLT | 16 | ETN0126215 |
| BEARING CONE DIFFERENTIAL LEFT | 1 | FP598 |
| BEARING CONE DIFFERENTIAL LEFT | 1 | ETN0031825 |
| BEARING CUP DIFFERENTIAL LEFT | 1 | FP592A |
| BEARING CUP DIFFERENTIAL LEFT | 1 | ETN0031824 |
| ADJUSTER DIFFERENTIAL BEARING LEFT | 1 | ETN0210286 |
| BOLT, SHIFT CYLINDER MOUNTING | 2 | ETN0128744 |
| GASKET PISTON COVER | 1 | DS128643 |
| GASKET PISTON COVER | 1 | ETN0128643 |
| CYLINDER DIFFERENTIAL SHIFT LOCK | 1 | ETN0511776 |
| O-RING PISTON | 1 | ETN0210180 |
| SWITCH, DIFFERENTIAL LOCK INDICATOR | 1 | ETN0129035 |
| ROD, PUSH SHIFT CYLINDER | 1 | ETN0210277 |
| BOLT, SHIFT FORK ADJUSTING | 1 | ETN0210191 |
| GUIDE, ACTUATOR SWITCH | 1 | ETN0210279 |
| SPRING, AXLE SHIFT PUSH ROD | 1 | ETN0031038 |
| PIN, ROLLER DIFFERENTIAL SHIFT FORK | 1 | ETN0210020 |
| YOKE DIFFERENTIAL LOCK W/PINION AND SCREW | 1 | ETN0219456 |
| CLUTCH, SLIDING DIFFERENTIAL | 1 | ETN0127211 |
| RING, SNAP CURVIC CLUTCH | 1 | ETN0129433 |
| CARRIER, DIFFERENTIAL W/BEARING CAPS | 1 | ETN0129427 |
| CLUTCH, CURVIC DIFFERENTIAL | 1 | ETN0126841 |
| NUT DIFFERENTIAL PINION GEAR BEARING | 1 | ETN0128049 |
| WASHER, SPACER COMPRESSION FLANGE | 1 | ETN0126940 |
| SEAL, OIL PINION GEAR | 1 | ETN0210724 |
| PLUG, PIPE COVER SIDE PORTAL | 1 | ETN0130806 |
| SCREW, SET | 1 | DS129946 |
| SCREW, SET | 1 | ETN0129946 |
| CASE, DIFFERENTIAL W/BOLTS 2.85 AND 3.70 RATIO | 1 | ETN0212007 |
| PISTON, SHIFT COVER | 1 | ETN0129290 |
| BEARING CONE PINION OUTER | 1 | TMHM813841 |
| BEARING CONE PINION OUTER | 1 | ETN0113868 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
