ETN0509727
DIFFERENTIAL, FORWARD REAR 6.50:1
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$4,299.95
$5,159.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
RELATED PARTS
SPECIFICATIONS
VMRS
027-015-000
OEM Description
DIFFERENTIAL, FORWARD REAR 6.50:1
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| CARRIER, DIFFERENTIAL W/BEARING CAPS DS404P | 1 | ETN0510022 |
| CUP, BEARING DIFFERENTIAL | 1 | FP563 |
| CUP, BEARING DIFFERENTIAL | 1 | ETN0090943 |
| BEARING, CONE DIFFERENTIAL | 1 | FP567 |
| BEARING, CONE DIFFERENTIAL | 1 | ETN0006082 |
| CASE, DIFFERENTIAL 5.29-7.17 RATIO | 1 | ETN0508656 |
| BOLT, DIFFERENTIAL CASE | 12 | ETN0127465 |
| GEAR, SIDE DIFFERENTIAL 41 SPLINE | 2 | ETN0127368 |
| WASHER, THRUST DIFFERENTIAL SIDE GEAR | 2 | ETN0127386 |
| WASHER, THRUST DIFFERENTIAL SPIDER GEAR | 4 | ETN0129305 |
| GEAR, PINION DIFFERENTIAL | 4 | DS133761 |
| GEAR, PINION DIFFERENTIAL | 4 | ETN0127364 |
| SPIDER, DIFFERENTIAL | 1 | ETN0127359 |
| WASHER, BOLT CARRIER BEARING CAP | 4 | ETN0210288 |
| NUT, BOLT DIFFERENTIAL CASE | 16 | ETN0126216 |
| BOLT, DIFFERENTIAL CASE | 16 | ETN0129686 |
| BEARING, ROLLER PILOT PINION | 1 | ETN0127484 |
| BEARING, CONE PINION | 1 | FP72218C |
| BEARING, CONE PINION | 1 | ETN0085439 |
| SHIM, BEARING CAGE PINION GEAR .823" | 1 | ETN0129115 |
| SHIM, BEARING CAGE PINION GEAR .815" | 1 | ETN0129099 |
| SHIM, BEARING CAGE PINION GEAR .816" | 1 | ETN0129101 |
| SHIM, BEARING CAGE PINION GEAR .817" | 1 | ETN0129103 |
| SHIM, BEARING CAGE PINION GEAR .818" | 1 | ETN0129105 |
| SHIM, BEARING CAGE PINION GEAR .819" | 1 | ETN0129107 |
| SHIM, BEARING CAGE PINION GEAR .820" | 1 | ETN0129109 |
| SHIM, BEARING CAGE PINION GEAR .821" | 1 | ETN0129111 |
| SHIM, BEARING CAGE PINION GEAR .824" | 1 | ETN0129117 |
| SHIM, BEARING CAGE PINION GEAR .825" | 1 | ETN0129119 |
| SHIM, BEARING CAGE PINION GEAR .826" | 1 | ETN0129120 |
| SHIM, BEARING CAGE PINION GEAR .828" | 1 | ETN0129121 |
| SHIM, BEARING CAGE PINION .829 MM | 1 | ETN0129122 |
| SHIM, BEARING CAGE PINION GEAR .830" | 1 | ETN0129123 |
| SHIM, BEARING CAGE PINION GEAR .831" | 1 | ETN0129124 |
| SHIM, BEARING CAGE PINION GEAR .832" | 1 | ETN0129125 |
| SHIM, BEARING CAGE PINION GEAR .833" | 1 | ETN0129126 |
| SHIM, BEARING CAGE PINION GEAR .810" | 1 | DS129090 |
| SHIM, BEARING CAGE PINION GEAR .811" | 1 | ETN0129091 |
| SHIM, BEARING CAGE PINION .812 MM | 1 | ETN0129093 |
| SHIM, BEARING CAGE PINION .814 MM | 1 | ETN0129097 |
| SHIM, BEARING CAGE PINION GEAR .810" | 1 | ETN0129090 |
| CARRIER, DIFFERENTIAL PINION GEAR W/CUP | 1 | ETN0127601 |
| BEARING, CUP PINION | 1 | FP72487 |
| CUP, BEARING PINION | 1 | ETN0014217 |
| BEARING | 1 | DS012495 |
| CUP, BEARING PINION | 1 | FP55437 |
| BEARING | 1 | ETN0012495 |
| BEARING, CONE OUTER PINION | 1 | TM55212C |
| BEARING- CONE PIN CAGE INNER /OTR | 1 | ETN0127535 |
| BOLT, PINION BEARING CAGE | 6 | DS210115 |
| BOLT, PINION BEARING CAGE | 6 | ETN0210115 |
| BOLT, DIFFERENTIAL CARRIER BEARING CAP | 4 | ETN0210095 |
| GEAR, HELICAL DRIVE DIFFERENTIAL | 1 | ETN0127523 |
| PIN, SPRING WINDING LEVER | 1 | ETN0118807 |
| NUT PINION SHAFT | 1 | ETN0126182 |
| GEAR SET, RING AND PINION DIFFERENTIAL 6.50:1 | 1 | ETN0211477 |
| CUP, BEARING INNER AXLE DIFFERENTIAL SIDE GEAR | 1 | FP29630 |
| CUP, BEARING INNER AXLE DIFFERENTIAL | 1 | ETN0127536 |
| BEARING, CONE INNER AXLE DIFFERENTIAL SIDE GEAR | 1 | ETN0110812 |
| BEARING, CONE INNER AXLE DIFFERENTIAL SIDE GEAR | 1 | FP29675 |
| GEAR, SIDE INTERMEDIATE AXLE DIFFERENTIAL REAR | 1 | DS10026797 |
| GEAR, SIDE INTERMEDIATE AXLE DIFFERENTIAL REAR | 1 | ETN0127645 |
| RING, SNAP | 1 | DS085997 |
| RING, SNAP | 1 | ETN0085997 |
| KIT, INTERMEDIATE AXLE DIFFERENTIAL CASE W/GEAR SET | 1 | DS134192 |
| KIT, INTERMEDIATE AXLE DIFFERENTIAL CASE W/GEAR SET | 1 | ETN0128634 |
| GEAR, HELICAL DRIVE DIFFERENTIAL WITH BUSHING | 1 | DS10000528 |
| GEAR, HELICAL DRIVE DIFFERENTIAL WITH BUSHING | 1 | ETN0127495 |
| PIN, COTTER | 2 | ETN0090873 |
| BUSHING, HELICAL DRIVE GEAR DIFFERENTIAL | 2 | ETN0129371 |
| WASHER, HELICAL GEAR | 1 | ETN0128702 |
| CLUTCH, SLIDING INTERMEDIATE AXLE DIFFERENTIAL | 1 | ETN0127510 |
| SHAFT, INPUT PD WITH NUT | 1 | DS504181 |
| SHAFT, INPUT PD WITH NUT | 1 | ETN0216226 |
| RETAINER, INPUT SHAFT BEARING REAR | 1 | ETN0128700 |
| CUP, BEARING | 1 | FP555S |
| BEARING CONE /ROLLERS | 1 | DS134303 |
| BEARING CONE /ROLLERS | 1 | ETN0820643 |
| COVER, INTERMEDIATE AXLE DIFFERENTIAL | 1 | ETN0129572 |
| BOLT, DIFFERENTIAL CASE | 9 | ETN0210091 |
| PIN, DOWEL CARRIER BEARING CAP | 2 | ETN0007641 |
| CUP, BEARING INPUT SHAFT | 1 | 2517663C91 |
| CUP, BEARING | 1 | FP552A |
| CUP, BEARING INPUT SHAFT | 1 | ETN1008912 |
| SEAL, "V" RING INPUT SHAFT BEARING POWER DIVIDER LOCK | 1 | ETN0128703 |
| CARRIER, DIFFERENTIAL INPUT SHAFT POWER DIVIDER LOCK | 1 | ETN0129575 |
| O-RING COVER | 1 | ETN0129576 |
| SEAL, OIL PINION AND INNER SHAFT | 1 | DS127591 |
| SEAL, OIL PINION AND INNER SHAFT | 1 | ETN0127591 |
| NUT DIFFERENTIAL PINION GEAR BEARING | 1 | ETN0128049 |
| ADJUSTER DIFFERENTIAL BEARING | 1 | ETN0129130 |
| TROUGH, LUBE | 1 | ETN0129577 |
| PUMP, OIL | 1 | ETN0127534 |
| BOLT, PUMP MOUNTING | 3 | ETN0127551 |
| CONNECTOR, PUMP DRIVE | 1 | ETN0128628 |
| PLUG, LUBE PUMP | 1 | ETN0019411 |
| PLUG, CARRIER DIFFERENTIAL | 5 | ETN0090897 |
| SCREEN, OIL FILTER | 1 | ETN0127649 |
| CUP, BEARING DIFFERENTIAL | 1 | FP493 |
| CUP, BEARING DIFFERENTIAL | 1 | ETN0009803 |
| O-RING PISTON | 1 | ETN0210180 |
| ROD PUSH DIFFERENTIAL LK SHIFT FORK | 1 | DS510870 |
| ROD PUSH DIFFERENTIAL LK SHIFT FORK | 1 | ETN0129582 |
| FORK- SHIFT I A D 14GEP/R/S/T | 1 | DS129783 |
| FORK- SHIFT I A D 14GEP/R/S/T | 1 | ETN0127506 |
| SPRING, COMPRESSION SHIFT FORK | 1 | ETN0129584 |
| O-RING COVER | 1 | ETN0129579 |
| BEARING, CONE DIFFERENTIAL | 1 | FP497 |
| BEARING, CONE DIFFERENTIAL | 1 | ETN0027813 |
| O-RING DIFFERENTIAL SIDE GEAR | 2 | ETN0127545 |
| RING SNAP PUSH ROD | 1 | ETN0129581 |
| ADJUSTER DIFFERENTIAL BEARING LEFT OR RIGHT | 1 | ETN0129128 |
CROSS REFERENCES
- DANA 0509727
- DANA 0509727
- DANA 509727
- DANA 509727
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
