ETN0509043
DIFFERENTIAL-R/R 5.60 RP461 36
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$4,999.95
$5,999.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
DIFFERENTIAL ASSEMBLY 5.60 23080P
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| CARRIER DIFFERENTIAL W/BEARING CAPS | 1 | ETN0127214 |
| BOLT, DIFFERENTIAL BEARING LOCK ADJUSTABLE | 2 | ETN0210601 |
| PLUG, EXPANSION SHIFT FORK UPPER | 1 | ETN0030703 |
| PLUG | 1 | ETN0009797 |
| COVER | 1 | ETN0045521 |
| WASHER- CARRIER BEARING CAP BOLT OR ST | 4 | ETN0032912 |
| WASHER, CARRIER TO HOUSING | 2 | DS090415 |
| WASHER, CARRIER TO HOUSING | 2 | ETN0090415 |
| SCREW SET CAP SCREW (2 PER) | 2 | DS020807 |
| SCREW SET CAP SCREW (2 PER) | 2 | ETN0020807 |
| GEAR, SUN DIFFERENTIAL | 1 | ETN0119902 |
| RETAINER, OUTPUT SHAFT BEARING FRONT | 1 | DS043178 |
| RETAINER, OUTPUT SHAFT BEARING FRONT | 1 | ETN0043178 |
| ADJUSTER DIFFERENTIAL BEARING LEFT | 1 | ETN0021637 |
| CUP, BEARING | 1 | FP42584 |
| CUP, BEARING | 1 | ETN0015092 |
| BEARING, CONE | 1 | FP42381 |
| BEARING, CONE | 1 | ETN0027876 |
| CASE, SUPPORT DIFFERENTIAL RIGHT | 1 | ETN0108138 |
| BOLT, RING GEAR | 8 | ETN0044358 |
| BOLT, BEARING CAP | 2 | ETN0127180 |
| BOLT, BEARING CAP | 2 | DS032732 |
| BOLT, BEARING CAP | 2 | ETN0032732 |
| PIN, IDLER GEAR | 4 | ETN0126302 |
| GEAR, IDLER | 4 | ETN0126306 |
| PLATE, HIGH SPEED CLUTCH DIFFERENTIAL DIFFERENTIAL | 1 | ETN0126307 |
| WASHER, THRUST HIGH SPEED PLATE | 1 | ETN0043271 |
| GEAR SET SINGLE REDUCTION DIFFERENTIAL 4.11:1 | 1 | ETN0122395 |
| CASE- SUPPORT LEFT HAND | 1 | ETN0126301 |
| NUT, HEXAGON RING GEAR BOLT | 8 | ETN0060599 |
| BEARING | 1 | FP68462 |
| BEARING | 1 | ETN0102660 |
| BEARING CUP | 1 | FP68712 |
| BEARING CUP | 1 | ETN0021632 |
| ADJUSTER DIFFERENTIAL BEARING LEFT | 1 | ETN0126305 |
| BEARING, ROLLER PINION REAR /REAR | 1 | ETN0126187 |
| BEARING | 1 | FP78215 |
| BEARING | 1 | ETN0027239 |
| SPACER | 1 | DS091679 |
| SPACER, PINION BEARING | 1 | ETN0031366 |
| SPACER | 1 | ETN0091679 |
| BEARING- CUP | 1 | FP78551 |
| BEARING- CUP | 1 | ETN0027238 |
| CARRIER, DIFFERENTIAL PINION DRIVE GEAR W/CUPS | 1 | ETN0210592 |
| BOLT, DIFFERENTIAL TO HOUSING 5/8" X 1 3/4" UNC | 6 | ETN0130187 |
| BUSHING, DOWEL CARRIER BEARING CAP | 2 | ETN0032730 |
| CUP, BEARING PINION CAGE | 1 | ETN0129561 |
| BEARING, CONE PINION CAGE | 1 | DS129562 |
| BEARING, CONE PINION CAGE | 1 | ETN0129562 |
| SEAL, OIL PINION BEARING | 1 | DS210724 |
| SEAL, OIL PINION BEARING | 1 | 573269C1 |
| NUT DIFFERENTIAL PINION GEAR BEARING | 1 | ETN0128049 |
| CASE, DIFFERENTIAL W/BOLTS | 1 | DS122417 |
| CASE, DIFFERENTIAL W/BOLTS | 1 | ETN0122417 |
| WASHER, THRUST SIDE PINION GEAR | 4 | ETN0108145 |
| BOLT | 8 | ETN0096284 |
| PIN- COTTER | 1 | ETN0090876 |
| LOCK DIFFERENTIAL BEARING ADJUSTER LEFT | 1 | ETN0078926 |
| WASHER, THRUST DIFFERENTIAL SIDE GEAR | 1 | ETN0083726 |
| BUSHING, DOWEL CARRIER BEARING CAP | 2 | ETN0037746 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
