ETN0509032
DIFFERENTIAL-R/R 4.56 RSS40 41
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$2,699.95
$3,239.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
DIFFERENTIAL ,R/R 4.56 14GGT
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| CARRIER, DIFFERENTIAL W/BEARING CAPS | 1 | ETN0098593 |
| ADJUSTER DIFFERENTIAL BEARING LEFT | 1 | ETN0021637 |
| ADJUSTER | 1 | ETN0039448 |
| CUP, BEARING | 1 | FP42584 |
| CUP, BEARING | 1 | DS019529 |
| CUP, BEARING | 1 | ETN0019529 |
| BEARING, CONE | 1 | FP42381 |
| BEARING, CONE | 1 | DS027666 |
| BEARING, CONE | 1 | ETN0027876 |
| BEARING, CONE | 1 | ETN0027666 |
| GEAR SET FRONT REAR DIFFERENTIAL 4.56:1 | 1 | DS121890 |
| GEAR SET FRONT REAR DIFFERENTIAL 4.56:1 | 1 | ETN0121890 |
| BOLT | 16 | DS067586 |
| BOLT | 16 | ETN0067586 |
| GEAR, DIFFERENTIAL SIDE LEFT OR RIGHT | 1 | ETN0120052 |
| WASHER, THRUST DIFFERENTIAL SIDE GEAR | 2 | ETN0027274 |
| BOLT, BEARING CAP | 4 | ETN0127180 |
| GEAR, SPIDER DIFFERENTIAL | 4 | ETN0086780 |
| WASHER, THRUST DIFFERENTIAL SPIDER GEAR | 4 | ETN0086781 |
| SPIDER, DIFFERENTIAL | 1 | ETN0086778 |
| BEARING, ROLLER PINION REAR /REAR | 1 | ETN0126187 |
| BEARING, CONE PINION | 1 | FP72212C |
| BEARING, CONE PINION | 1 | FP78215 |
| BEARING, CONE PINION | 1 | ETN0014218 |
| CARRIER, DIFFERENTIAL PINION DRIVE GEAR W/CUPS | 1 | ETN0210592 |
| CUP, BEARING PINION | 1 | FP72487 |
| CUP, BEARING PINION | 1 | FP78551 |
| CUP, BEARING PINION | 1 | ETN0014217 |
| SPACER, PINION BEARING | 1 | ETN0031366 |
| WASHER- CARRIER BEARING CAP BOLT OR ST | 4 | ETN0032912 |
| BOLT, CAGE 5/8" X 1 3/4" UNC | 6 | ETN0130187 |
| BOLT, CAGE 5/8" X 1 3/4" UNC | 6 | ETN0113327 |
| SEAL, OIL PINION GEAR | 1 | ETN0210724 |
| WASHER, COMPANION FLANGE NUT | 1 | DS128049 |
| WASHER, COMPANION FLANGE NUT | 1 | ETN0210509 |
| NUT PINION | 1 | ETN0210508 |
| NUT | 1 | DS060600 |
| NUT | 1 | ETN0060600 |
| BOLT | 12 | ETN0088503 |
| LOCK, DIFFERENTIAL BEARING ADJUSTER RIGHT | 2 | ZBP0014275 |
| LOCK, DIFFERENTIAL BEARING ADJUSTER RIGHT | 2 | ETN0014275 |
| PIN- COTTER | 2 | ETN0090876 |
| 42584- BEARING CUP | 1 | ZBP0015092 |
| CUP, BEARING | 1 | FP653 |
| BEARING, CONE DIFFERENTIAL | 1 | FP665 |
| BUSHING, DOWEL CARRIER BEARING CAP | 2 | ETN0032730 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
