ETN0508198
DIFFERENTIAL-R/R 5.29 RC461 36
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$5,699.95
$6,839.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
DIFFERENTIAL- REAR 5.29 14AEU
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| CARRIER, DIFFERENTIAL W/BEARING CAPS | 1 | ETN0098590 |
| SHAFT, SHIFT FORK DIFFERENTIAL | 1 | ETN0113801 |
| PLUG, EXPANSION 15/16" | 1 | 172541 |
| PLUG, EXPANSION SHIFT FORK UPPER | 1 | ETN0030703 |
| FORK- SHIFT AXLE | 1 | ETN0084508 |
| STUD, SHIFT CHAMBER MOUNTING OR MOTOR | 2 | ETN0119863 |
| SEAL, SHIFT MOTOR TO CARRIER | 1 | ETN0119855 |
| COVER | 1 | ETN0103517 |
| WASHER, LOCK 7/16" | 2 | ETN0119857 |
| NUT, HEXAGON 7/16" UNF | 2 | ZBP0063028 |
| NUT, HEXAGON 7/16" UNF | 2 | ETN0063028 |
| BOLT, BEARING CAP | 4 | DS032732 |
| BOLT, BEARING CAP | 4 | ETN0032732 |
| ADJUSTER | 1 | ETN0082451 |
| ADJUSTER DIFFERENTIAL BEARING LEFT | 1 | ETN0021637 |
| CUP, BEARING REAR | 1 | FP68712 |
| CUP, BEARING | 1 | FP42584 |
| BEARING, CONE DIFFERENTIAL | 1 | FP42381 |
| BEARING, CONE PINION | 1 | FP72212C |
| BEARING, CONE PINION | 1 | ETN0014218 |
| BEARING, CONE DIFFERENTIAL | 1 | 58233R91 |
| WASHER- CARRIER BEARING CAP BOLT OR ST | 4 | ETN0032912 |
| BOLT | 12 | ETN0088503 |
| WASHER, THRUST DIFFERENTIAL SIDE GEAR | 1 | ETN0027274 |
| WASHER | 1 | ETN0082442 |
| WASHER, THRUST DIFFERENTIAL SPIDER GEAR | 4 | ETN0086781 |
| GEAR SET, RING AND PINION DIFFERENTIAL 5.29:1 | 1 | ETN0211335 |
| BOLT | 16 | ETN0082454 |
| CLUTCH, SLIDING DIFFERENTIAL | 1 | ETN0086576 |
| BOLT AXLE HOUSING COVER | 1 | ETN0211361 |
| BOLT AXLE HOUSING COVER | 1 | ETN0084827 |
| DRIVER | 1 | ETN0082449 |
| RING | 1 | ETN0082444 |
| PLATE, HIGH SPEED CLUTCH DIFFERENTIAL DIFFERENTIAL | 1 | ETN0082447 |
| RING | 1 | ETN0082621 |
| SPRING, AXLE SHIFT PUSH ROD | 12 | ETN0082448 |
| COVER | 1 | ETN0103190 |
| BEARING, ROLLER PINION REAR /REAR | 1 | ETN0126187 |
| LOCK, DIFFERENTIAL BEARING ADJUSTER RIGHT | 1 | ZBP0014275 |
| LOCK, DIFFERENTIAL BEARING ADJUSTER RIGHT | 1 | ETN0014275 |
| BEARING, CONE PINION | 1 | FP78215 |
| BEARING, CONE PINION | 1 | 385581C91 |
| CARRIER, DIFFERENTIAL PINION DRIVE GEAR W/CUPS | 1 | ETN0210592 |
| CUP, BEARING PINION | 1 | FP72487 |
| CUP, BEARING PINION | 1 | FP78551 |
| CUP, BEARING PINION | 1 | 68875R1 |
| CUP, BEARING PINION | 1 | ETN0014217 |
| BOLT, CAGE 5/8" X 1 3/4" UNC | 6 | ETN0130187 |
| BOLT, CAGE 5/8" X 1 3/4" UNC | 6 | ETN0113327 |
| SEAL OIL PINION | 1 | DS210724 |
| SEAL OIL PINION | 1 | ETN0113866 |
| PIN- COTTER | 1 | ETN0090876 |
| NUT PINION | 1 | DS128049 |
| NUT PINION | 1 | ETN0210508 |
| NUT | 16 | DS060600 |
| NUT | 16 | ETN0060600 |
| WASHER, COMPANION FLANGE NUT | 1 | ETN0210509 |
| BUSHING, DOWEL CARRIER BEARING CAP | 4 | ETN0032730 |
| LOCK | 1 | ETN0045448 |
| 42584- BEARING CUP | 1 | ZBP0015092 |
| 68462- BEARING CONE | 1 | ZBP0102660 |
| BEARING | 1 | ETN0027239 |
| BEARING, CONE DIFFERENTIAL | 1 | FP68462 |
| CAP SCREW | 2 | ETN0012562 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
