ETN0219369
DIFFERENTIAL NO SPIN 4.88
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$7,099.95
$8,519.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
VMRS
027-015-000
OEM Description
DIFF-ASM HEAD 19060T 4.88 NS
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| CARRIER | 1 | ETN0067759 |
| BOLT, DIFFERENTIAL BEARING LOCK ADJUSTABLE | 2 | ETN0210601 |
| PLUG, EXPANSION SHIFT FORK UPPER | 1 | ETN0030703 |
| SHAFT, SHIFT FORK DIFFERENTIAL | 1 | ETN0113801 |
| YOKE, SHIFT AXLE | 1 | ETN0032613 |
| STUD, SHIFT CHAMBER MOUNTING OR MOTOR | 2 | ETN0119863 |
| SEAL, SHIFT MOTOR TO CARRIER | 1 | ETN0119855 |
| PLUG | 1 | ETN0009797 |
| WASHER, LOCK 7/16" | 2 | ETN0119857 |
| NUT, HEXAGON 7/16" UNF | 2 | ZBP0063028 |
| NUT, HEXAGON 7/16" UNF | 2 | ETN0063028 |
| CLUTCH, SLIDING DIFFERENTIAL | 1 | ETN0113596 |
| ADJUSTER DIFFERENTIAL BEARING LEFT | 1 | ETN0110243 |
| CUP, BEARING DIFFERENTIAL | 1 | DS134301 |
| CUP, BEARING DIFFERENTIAL | 1 | ETN0129566 |
| BEARING, CONE DIFFERENTIAL | 1 | DS134300 |
| BEARING, CONE DIFFERENTIAL | 1 | ETN0129565 |
| CASE, SUPPORT GEAR | 1 | ETN0110148 |
| BOLT, RING GEAR | 8 | ETN0044358 |
| WASHER, THRUST DIFFERENTIAL SIDE GEAR | 1 | ETN0127386 |
| SHAFT, IDLER GEAR DIFFERENTIAL | 4 | ETN0027861 |
| GEAR, IDLER PINION | 4 | ETN0027835 |
| WASHER, THRUST GEAR SUPPORT CASE | 1 | ETN0043270 |
| GEAR SET, RING AND PINION DIFFERENTIAL 4.88:1 | 1 | ETN0219015 |
| CASE, SUPPORT GEAR | 1 | ETN0027838 |
| NUT, HEXAGON RING GEAR BOLT | 8 | ETN0060599 |
| BEARING, CONE DIFFERENTIAL | 1 | FP56425 |
| BEARING, CONE DIFFERENTIAL | 1 | ETN0027817 |
| BEARING, CUP | 1 | FP56650 |
| BEARING, CUP | 1 | ETN0027816 |
| WIRE | 4 | ETN0090538 |
| ADJUSTER DIFFERENTIAL BEARING LEFT | 1 | ETN0056932 |
| BEARING, ROLLER REAR PINION | 1 | ETN0830398 |
| BEARING | 1 | FP72200C |
| BEARING | 1 | ETN0045460 |
| CARRIER, DIFFERENTIAL PINION GEAR W/CUP | 1 | ETN0119820 |
| BOLT, SPECIAL | 6 | ETN0113325 |
| BEARING | 1 | FP55200C |
| BEARING | 1 | ETN0012496 |
| SEAL, OIL PINION GEAR BEARING | 1 | ETN0127721 |
| NUT, MOUNTING COMPANION FLANGE M36 X 1.5-4H | 1 | ETN0127589 |
| BOLT, HEXAGON HEAD DIFFERENTIAL CASE | 8 | ETN0096283 |
| GEAR, SIDE DIFFERENTIAL | 2 | ETN0110525 |
| LOCK, DIFFERENTIAL BEARING ADJUSTER | 1 | ETN0013377 |
| GEAR, PINION DIFFERENTIAL | 4 | ETN0104139 |
| WASHER, THRUST DIFFERENTIAL SPIDER GEAR | 4 | ETN0027810 |
| SPIDER, DIFFERENTIAL | 1 | DS128003 |
| SPIDER, DIFFERENTIAL | 1 | ETN0038289 |
| DIFFERNTIAL | 1 | ETN0110829 |
| PIN, COTTER | 1 | ETN0090873 |
| LOCK | 1 | DS037745 |
| LOCK | 1 | ETN0037745 |
| PORTADIF TAPAS 065T-ENS | 1 | ETN0107494 |
| COVER, SHIFT CHAMBER | 1 | ETN0032611 |
| SPRING | 1 | DS119855 |
| SPRING | 1 | ETN0035585 |
| BUSHING, DOWEL CARRIER BEARING CAP | 2 | ETN0037746 |
CROSS REFERENCES
- DANA 0219369
- DANA 0219369
- DANA 219369
- DANA 219369
- FORDPRD 6C4O 4200FA
- FORDSVC 6C4Z 4200F
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
