ETN0219104
DIFFERENTIAL, FORWARD REAR 3.70/5.05:1
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$8,999.95
$10,799.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
VMRS
027-015-000
OEM Description
DIFFERENTIAL, FORWARD REAR 3.70/5.05:1
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| CARRIER- DIFFERENTIAL W/BEARING CAPS | 1 | ETN0115825 |
| LOCK, DIFFERENTIAL BEARING ADJUSTER | 1 | ETN0013377 |
| LOCK WASHER | 9 | ETN0090417 |
| PLUG- DRAIN PDV CASE | 1 | ETN0090325 |
| PLUG, EXPANSION 15/16" | 1 | 172541 |
| SCREEN, OIL FILTER | 1 | DS102611 |
| SCREEN, OIL FILTER | 1 | ETN0102611 |
| GEAR, OIL PUMP | 1 | ETN0111448 |
| NUT, LOCK | 1 | ETN0111451 |
| O-RING | 1 | 366581R1 |
| O-RING | 1 | ETN0102620 |
| PIN | 2 | ETN0102617 |
| PIN 1/4 X .750 PLN HDN DOWEL | 2 | 20040R1 |
| CAP SCREW | 4 | ETN0102618 |
| PIN, COTTER | 1 | ETN0090873 |
| WASHER | 4 | ETN0090419 |
| YOKE, SHIFT AXLE | 1 | ETN0107620 |
| WASHER THRUST DIFFERENTIAL SPIDER GEAR | 1 | ETN0027827 |
| NUT, HEXAGON RING GEAR BOLT | 8 | ETN0060599 |
| O-RING | 1 | ETN0096911 |
| BUSHING | 1 | ETN0108223 |
| SPRING, AXLE SHIFT PUSH ROD | 1 | ETN0126705 |
| GROMMET, RUBBER | 1 | ETN0032832 |
| PLUG, EXPANSION SHIFT FORK UPPER | 1 | ETN0030703 |
| PLUG | 1 | ETN0009797 |
| GROMMET | 1 | 684975R1 |
| GROMMET | 1 | ETN0060817 |
| BOLT CAP SCREW | 4 | DS079363 |
| BOLT CAP SCREW | 4 | ETN0079363 |
| NUT | 1 | ETN0090206 |
| O-RING | 1 | DS096912 |
| O-RING | 1 | ETN0096912 |
| WASHER DIFFERENTIAL SHIFT PUSH ROD | 1 | ETN0111406 |
| WASHER, CARRIER TO HOUSING | 1 | DS090415 |
| WASHER, CARRIER TO HOUSING | 1 | ETN0090415 |
| BOLT 7/16" X 1 1/4" | 2 | 70427R1 |
| SEAL, FELT AIR SHIFT CYLINDER | 1 | 86073R1 |
| SHAFT, SHIFT FORK DIFFERENTIAL | 1 | ETN0113801 |
| FITTING, SOCKET HEAD PLUG 3/4" NPT | 1 | 9409949 |
| PIN, DOWEL CARRIER BEARING CAP | 2 | ETN0007641 |
| YOKE, SHIFT AXLE | 1 | ETN0032613 |
| SEAL, SHIFT MOTOR TO CARRIER | 1 | ETN0119855 |
| STUD, SHIFT CHAMBER MOUNTING OR MOTOR | 2 | ETN0119863 |
| CYLINDER, AIR 2 SPEED TRACTION CONTROL | 1 | ETN0073503 |
| BOLT, BEARING CAP | 4 | DS032732 |
| BOLT, BEARING CAP | 4 | ETN0032732 |
| WASHER, LOCK 7/16" | 2 | ETN0119857 |
| NUT, LOCK ENGINE SUPPORT SHAFT 7/16" UNF 7/16" NF | 2 | 273896 |
| CLUTCH, SLIDING DIFFERENTIAL | 1 | ETN0113596 |
| ADJUSTER DIFFERENTIAL BEARING LEFT | 1 | ETN0056932 |
| ADJUSTER DIFFERENTIAL BEARING LEFT | 1 | ETN0110243 |
| CUP, BEARING DIFFERENTIAL | 1 | FP493 |
| BEARING, CUP | 1 | FP56650 |
| BEARING, CUP | 1 | ETN0027816 |
| CUP, BEARING DIFFERENTIAL | 1 | ETN0009803 |
| WASHER- CARRIER BEARING CAP BOLT OR ST | 4 | ETN0032912 |
| BEARING, CONE DIFFERENTIAL | 1 | FP497 |
| BEARING, CONE DIFFERENTIAL | 1 | FP56425 |
| BEARING, CONE DIFFERENTIAL | 1 | ETN0027817 |
| BEARING, CONE DIFFERENTIAL | 1 | ETN0027813 |
| GEAR SET, RING AND PINION DIFFERENTIAL 3.70:1 | 1 | ETN0218999 |
| BOLT, RING GEAR | 8 | ETN0044358 |
| CASE, SUPPORT GEAR | 1 | ETN0027838 |
| CASE, SUPPORT GEAR | 1 | ETN0110148 |
| WASHER, THRUST GEAR SUPPORT CASE | 1 | ETN0043270 |
| PLATE, HIGH SPEED CLUTCH DIFFERENTIAL DIFFERENTIAL | 1 | ETN0056931 |
| SHAFT, IDLER GEAR DIFFERENTIAL | 4 | ETN0027861 |
| GEAR, IDLER PINION | 4 | ETN0027835 |
| BOLT, HEXAGON HEAD DIFFERENTIAL CASE | 8 | ETN0096283 |
| GEAR, SIDE DIFFERENTIAL 41 SPLINE | 2 | ETN0110527 |
| WASHER THRUST DIFFERENTIAL SPIDER GEAR | 2 | DS127386 |
| GEAR, PINION DIFFERENTIAL | 4 | ETN0104139 |
| WASHER, THRUST DIFFERENTIAL SPIDER GEAR | 4 | ETN0027810 |
| SPIDER, DIFFERENTIAL | 1 | DS128003 |
| SPIDER, DIFFERENTIAL | 1 | ETN0038289 |
| BEARING | 1 | FPHM807049 |
| BEARING, CONE PINION | 1 | FP72218C |
| BEARING | 1 | ETN0110846 |
| BEARING, CONE PINION | 1 | ETN0085439 |
| CARRIER, DIFFERENTIAL PINION DRIVE GEAR | 1 | ETN0110731 |
| BEARING | 1 | FPHM807010 |
| CUP, BEARING PINION | 1 | FP72487 |
| CUP, BEARING PINION | 1 | ETN0014217 |
| BEARING | 1 | ETN0035502 |
| BUSHING, DOWEL CARRIER BEARING CAP | 2 | ETN0032730 |
| BOLT | 6 | ETN0062158 |
| WASHER, STUD BEARING CAGE PINION GEAR | 6 | ETN0037207 |
| GEAR, HELICAL DRIVE DIFFERENTIAL | 1 | ETN0110845 |
| LOCK | 1 | DS037745 |
| LOCK | 1 | ETN0037745 |
| SHAFT, OUTPUT POWER DIVIDER LOCK | 1 | ETN0115123 |
| O-RING | 2 | ETN0046526 |
| RING, SNAP | 2 | ETN0085994 |
| BEARING | 1 | ETN0110811 |
| BEARING, CONE INNER AXLE DIFFERENTIAL SIDE GEAR | 1 | ETN0110812 |
| BUSHING, DOWEL CARRIER BEARING CAP | 2 | ETN0037746 |
| GEAR, INTERMEDIATE AXLE DIFFERENTIAL FRONT, REAR | 1 | ETN0110810 |
| SPRING, AXLE SHIFT PUSH ROD | 1 | ETN0051238 |
| BUSHING, THRUST OUTPUT SHAFT | 1 | ETN0051228 |
| BOLT | 8 | DS085438 |
| BOLT | 8 | ETN0085438 |
| NUT | 8 | 27036R1 |
| NUT | 8 | ETN0057637 |
| GEAR | 4 | ETN0095214 |
| WASHER, THRUST DIFFERENTIAL SPIDER GEAR | 4 | ETN0127785 |
| BOLT | 2 | ETN0037747 |
| SPIDER, DIFFERENTIAL | 1 | ETN0127783 |
| BEARING, ROLLER INNER AXLE DIFFERENTIAL PINION REAR | 1 | DS830398 |
| BEARING, ROLLER INNER AXLE DIFFERENTIAL PINION REAR | 1 | ETN0129175 |
| RING, SNAP | 1 | DS085997 |
| RING, SNAP | 1 | ETN0085997 |
| WASHER, LOCK 9/16 INTAKE PHC | 6 | 138555 |
| BOLT 1/2" X 2" | 4 | 25279R1 |
| FITTING, BUSHING 1/4" NPT X 1/8" NPTF | 1 | 444024 |
| NUT PINION SHAFT | 1 | ETN0126182 |
| NUT DIFFERENTIAL PINION GEAR BEARING | 1 | ETN0128049 |
| GEAR, INTERMEDIATE AXLE DIFFERENTIAL WITH BUSHING | 1 | ETN0128042 |
| NUT, LOCK SHIFT CYLINDER PISTON ROD POWER DIVIDER LOCK | 1 | ETN1006779 |
| CUP, BEARING | 1 | FP29620 |
| BEARING, CONE INNER AXLE DIFFERENTIAL SIDE GEAR | 1 | FP29675 |
| BEARING, CONE | 1 | FP3979 |
| BUSHING, SIDE GEAR DIFFERENTIAL POWER DIVIDER LOCK | 2 | DS085991 |
| BUSHING, SIDE GEAR DIFFERENTIAL POWER DIVIDER LOCK | 2 | ETN0085991 |
| CUP, BEARING | 1 | FPJM511910 |
| WASHER, THRUST DIFFERENTIAL SIDE GEAR | 1 | ETN0085429 |
| WASHER HELICAL GEAR TO PINION GEAR | 1 | ETN0045478 |
| CLUTCH, SLIDING INTERMEDIATE AXLE DIFFERENTIAL | 1 | ETN0128016 |
| SHAFT, INPUT POWER DIVIDER LOCK | 1 | ETN0115126 |
| BEARING | 1 | SKF3979 |
| BEARING | 1 | ETN0091136 |
| BEARING | 1 | SKFJM511910 |
| BEARING | 1 | ETN0098388 |
| CARRIER, DIFFERENTIAL INPUT SHAFT W/CUPS | 1 | ETN0211888 |
| BOLT | 5 | ETN0113324 |
| WASHER, LOCK COVER BOLT 1/2" | 5 | 135629 |
| WASHER, LOCK COVER BOLT 1/2" | 5 | ETN0090414 |
| SEAL, OIL INPUT SHAFT BEARING POWER DIVIDER LOCK | 1 | DS127719 |
| SEAL, OIL INPUT SHAFT BEARING POWER DIVIDER LOCK | 1 | ETN0127719 |
| NUT, MOUNTING COMPANION FLANGE M36 X 1.5-4H | 1 | ETN0127589 |
| COVER, INTERMEDIATE AXLE DIFFERENTIAL | 1 | ETN0102627 |
| BOLT | 4 | ETN0012063 |
| BOLT 9/16" X 1 3/4" | 5 | 25312R1 |
| BOLT 9/16" X 2 1/2" | 4 | 25320R1 |
| BOLT | 5 | ETN0090069 |
CROSS REFERENCES
- DANA 0219104
- DANA 0219104
- DANA 219104
- DANA 219104
