ETN0216064
DIFFERENTIAL FRONT DRIVE 4.11:1
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$3,999.95
$4,799.94
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
VMRS
027-015-000
OEM Description
DIFFERENTIAL FRONT DRIVE 4.11:1
Weight
216.45 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| CARRIER, DIFFERENTIAL W/BEARING CAPS | 1 | ETN0121737 |
| WASHER, THRUST DIFFERENTIAL SPIDER GEAR | 4 | DS025968 |
| WASHER, THRUST DIFFERENTIAL SPIDER GEAR | 4 | ETN0025968 |
| WASHER, THRUST DIFFERENTIAL SIDE GEAR | 2 | ETN0127837 |
| GEAR SET, RING AND PINION DIFFERENTIAL 4.11:1 | 1 | ETN0122231 |
| BEARING, ROLLER PINION REAR /REAR | 1 | ETN0210353 |
| NUT COMPANION FLANGE | 1 | ETN0210133 |
| WASHER, COMPANION FLANGE NUT | 1 | ETN0210114 |
| BEARING, CONE DIFFERENTIAL | 2 | FP497 |
| BEARING, CONE DIFFERENTIAL | 2 | ST2040 |
| CUP, BEARING | 2 | FP25520 |
| CUP, BEARING | 2 | ST987 |
| SEAL, OIL PINION GEAR | 1 | ETN0119427 |
| SHIM, BEARING CAGE PINION GEAR .010" | 1 | ETN0107569 |
| SHIM, BEARING CAGE PINION GEAR .005" | 1 | ETN0107568 |
| ADJUSTER DIFFERENTIAL BEARING LEFT | 2 | ETN0210389 |
| ADJUSTER DIFFERENTIAL BEARING RIGHT | 2 | ETN0210108 |
| BEARING CONE /ROLLERS | 1 | 917218R91 |
| BEARING ROLLER | 1 | TM55175C |
| BEARING ROLLER | 1 | 306018C91 |
| CUP, BEARING | 1 | FPHM903210 |
| CUP, BEARING | 1 | 917217R1 |
| BOLT, DIFFERENTIAL CASE | 12 | ETN0210469 |
| BOLT, RING GEAR TO CASE | 16 | ETN0126218 |
| CASE, DIFFERENTIAL | 1 | ETN0121734 |
| CUP | 1 | ST992 |
| BEARING | 2 | SKFBR3994 |
| BEARING | 2 | ST2073 |
| PIN COTTER | 2 | DS090873 |
| PIN COTTER | 2 | ETN0126156 |
| NUT, HEXAGON RING TO CASE BOLT | 16 | ETN0126217 |
| CARRIER, DIFFERENTIAL PINION DRIVE GEAR | 1 | ETN0126825 |
| BOLT, PINION BEARING CAGE | 6 | DS210115 |
| BOLT, PINION BEARING CAGE | 6 | ETN0210115 |
| BOLT, BEARING CAP | 4 | ETN0210134 |
| WASHER, FLAT | 4 | ETN0210175 |
CROSS REFERENCES
- DANA 0216064
- DANA 0216064
- DANA 216064
- DANA 216064
- FABCO 216064
- FABCO 216064
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
