ETN0214835
DIFFERENTIAL-RR 3.08 23105S 36
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$4,299.95
$5,159.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
DIFFERENTIAL, REAR 3.08 14097
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| CARRIER | 1 | ETN0119792 |
| CUP, BEARING | 1 | 564121C1 |
| BEARING, CONE | 1 | 564122C91 |
| ADJUSTER DIFFERENTIAL BEARING LEFT | 1 | ETN0113884 |
| CUP, BEARING | 1 | SKF52618 |
| CUP, BEARING | 1 | 64371H |
| BEARING, CONE | 1 | FP52400 |
| BEARING, CONE | 1 | 64370H |
| BOLT | 12 | ETN0088503 |
| GEAR, SIDE DIFFERENTIAL | 2 | ETN0093401 |
| WASHER, THRUST DIFFERENTIAL SIDE GEAR | 2 | ETN0027274 |
| WASHER- CARRIER BEARING CAP BOLT OR ST | 4 | ETN0032912 |
| WASHER, THRUST DIFFERENTIAL SPIDER GEAR | 4 | ETN0086781 |
| GEAR, SPIDER DIFFERENTIAL | 4 | ETN0086780 |
| SPIDER, DIFFERENTIAL | 1 | ETN0086778 |
| NUT | 16 | ETN0084497 |
| BOLT | 16 | ETN0113888 |
| BEARING ASSEMBLY. ROLLER | 1 | DS126187 |
| BEARING ASSEMBLY. ROLLER | 1 | 1651565C91 |
| BEARING, CONE PINION | 1 | ETN0126286 |
| CUP, BEARING PINION | 1 | ETN0126287 |
| BOLT, BEARING CAP | 4 | DS032732 |
| BOLT, BEARING CAP | 4 | ETN0032732 |
| CARRIER, DIFFERENTIAL PINION GEAR W/CUPS | 1 | ETN0126290 |
| BOLT | 6 | ETN0113867 |
| BEARING, CUP OUTER PINION | 1 | FPHM813810 |
| BEARING, CUP OUTER PINION | 1 | 152454R1 |
| BEARING CONE PINION OUTER | 1 | 304661C91 |
| WASHER, SPACER COMPRESSION FLANGE | 1 | ETN0126940 |
| SEAL OIL PINION | 1 | DS210724 |
| SEAL OIL PINION | 1 | ETN0113866 |
| NUT- COMP FLANGE MOUNTING | 1 | 440302C1 |
| NUT- COMP FLANGE MOUNTING | 1 | ETN0095262 |
| GEAR SET, RING AND PINION DIFFERENTIAL 3.08:1 | 1 | ETN0121243 |
| PIN, COTTER 1/4" X 1-1/4" | 2 | 103419 |
| LOCK, DIFFERENTIAL BEARING ADJUSTER RIGHT | 2 | ZBP0014275 |
| LOCK, DIFFERENTIAL BEARING ADJUSTER RIGHT | 2 | ETN0014275 |
| BOLT, ADJUSTING DRIVE GEAR THRUST | 1 | ETN0126193 |
| NUT DRIVE GEAR ADJUSTABLE SCREW | 1 | ETN0210184 |
| BUSHING, DOWEL CARRIER BEARING CAP | 4 | ETN0032730 |
| ADJUSTER DIFFERENTIAL BEARING RIGHT | 1 | ETN0113885 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
