574518C92
DIFFERENTIAL, REAR 6.14:1
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$2,899.95
$3,479.94
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
RELATED PARTS
SPECIFICATIONS
VMRS
027-015-000
OEM Description
DIFFERENTIAL REAR 6.14 14057
Weight
416.87 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| NUT HEXAGON LK COMP FLANGE | 1 | 578881C1 |
| CARRIER, DIFFERENTIAL PINION GEAR | 1 | 482782C91 |
| CUP, BEARING | 1 | FPH715311 |
| CUP, BEARING | 1 | 107580R1 |
| BEARING, CONE | 1 | FPH715343 |
| BEARING, CONE | 1 | 860954R91 |
| GEAR SET DIFFERENTIAL 6.14:1 | 2 | 597254C91 |
| BEARING, ROLLER | 1 | FPMU1308TM |
| BEARING, ROLLER | 1 | 472658C91 |
| CARRIER, DIFFERENTIAL W/BEARING CAPS | 1 | 451918C92 |
| ADJUSTER DIFFERENTIAL BEARING | 2 | 161066R1 |
| LOCK, DIFFERENTIAL BEARING ADJUSTER | 2 | 157491R2 |
| PIN, COTTER 3/16" X 1" | 2 | 103407 |
| BOLT, SPECIAL | 4 | 24896R1 |
| BOLT, SPECIAL | 4 | 1691246C1 |
| WASHER, FLAT | 4 | 25712R1 |
| CUP, BEARING DIFFERENTIAL | 2 | FP56650 |
| CUP, BEARING DIFFERENTIAL | 2 | 65546D |
| BEARING, CONE | 2 | FP56425 |
| BEARING, CONE | 2 | 57327R91 |
| NUT, LOCK 5/8" UNF | 8 | 9411658 |
| NUT, LOCK 5/8" UNF | 8 | 274639 |
| CASE, DIFFERENTIAL | 1 | 161080R3 |
| WASHER, THRUST SIDE GEAR DIFFERENTIAL | 2 | 161064R1 |
| WASHER, THRUST DIFFERENTIAL SPIDER GEAR | 4 | 161061R2 |
| RIVET DIFFERENTIAL DRIVE GEAR | 12 | 161060R1 |
| CASE, FLANGE HALF DIFFERENTIAL | 1 | 161091R5 |
| BOLT | 8 | 1691248C1 |
| SEAL, OIL PINION | 1 | 1691143C2 |
| SEAL, OIL PINION | 1 | 1651281C91 |
| SPACER, PINION BEARING | 1 | 892790R1 |
| BEARING, CONE PINION | 1 | 483067C91 |
| BOLT | 6 | 1691247C1 |
| CUP, BEARING | 1 | FPHM813810 |
| CUP, BEARING | 1 | 483068C1 |
| SCOOP, OIL | 1 | 336247C2 |
| BOLT 1/4" X 1/2" | 2 | 25752R1 |
CROSS REFERENCES
- DANA 057CA108 8
- DANA 057CA108 8
- DANA 057CA108 8X
- DANA 057CA108 8X
- DANA 057CA108-8X
- DANA 057CA108-8X
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
