2613266C91
DIFFERENTIAL CARRIER R/R 3.42
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$3,899.95
$4,679.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
DIFFERENTIAL CARRIER R/R 3.42
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| BEARING (CONE), DIFFERENTIAL | 2 | 2613564C1 |
| CONE-TAPER-BEARING | 2 | 594A |
| SCREW, THRUST DRIVE GEAR | 1 | 2508423C1 |
| RING LOCK DIFFERENTIAL ADJUSTER | 2 | 2613563C1 |
| BEARING, CUP PINION | 1 | FP72487 |
| CUP, BEARING PINION | 1 | H715311 |
| BEARING CUP- INNER | 2 | 2602335C1 |
| WASHER FLAT BEARING CAP | 4 | 42X1021 |
| BOLT, DRIVE GEAR | 1 | 1670534C1 |
| BOLT DIFFERENTIAL CARRIER BEARING CAP | 4 | MS2201201 |
| WASHER, PINION SHAFT 2.38" O.D. X 1.53" I.D. X .12" THICK | 1 | 452436C1 |
| NUT LOCK INPUT /OUTPUT SHAFT | 1 | 40X1237 |
| ASSEMBLY CARRIER AND CAP | 1 | 2613559C1 |
| SPACER, PINION BEARING INNER | 1 | 2613561C1 |
| WASHER, BOLT CARRIER TO HOUSING | 1 | 226846R1 |
| SEAL, PINION OIL | 1 | 2590277C1 |
| CONE-TAPER-BEARING | 1 | 72212C |
| NUT, HEXAGON LOCK METRIC | 1 | 1691622C1 |
| NUT, SPECIAL THRUST SCREW | 1 | 40X1016 |
| CONE AND ROLLERS TA | 1 | H715334 |
| BLOCK-THRUST | 1 | 2297P8336 |
| CAP SCREW | 4 | 41X1669 |
CROSS REFERENCES
- MERITOR A3200G2217342
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
