2608258C91
DIFFERENTIAL CARRIER F/R 4.11 DCDL W/PUMP
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$4,499.95
$5,399.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
DIFFERENTIAL CARRIER F/R 4.11 DCDL W/PUMP
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| O-RING AIR CYLINDER | 1 | 1653983C1 |
| SCREEN, OIL FILTER | 1 | 1670482C1 |
| CASE DIFFERENTIAL NEST ASSEMBLY | 1 | A13235H3310 |
| CASE DIFFERENTIAL NEST ASSEMBLY | 1 | 2510329C91 |
| CONE, BEARING INPUT SHAFT | 1 | 2613342C1 |
| CONE BEARING MAIN DIFFERENTIAL | 2 | 2613366C1 |
| CONE, BEARING REAR SIDE | 1 | 2613354C1 |
| BEARING, CONE OUT PINION | 1 | 2613560C1 |
| SEAL, OIL INPUT SHAFT | 1 | 2502761C1 |
| PUMP DIFFERENTIAL 14X | 1 | 2613335C1 |
| SHIM, BEARING SPACER PINION GEAR .010" | 4 | 242817R1 |
| SHIM, BEARING SPACER PINION GEAR .005" | 2 | 242816R1 |
| SHIM PIN GEAR BEARING SPACER .003 | 3 | 242815R1 |
| SPACER, PINION BEARING .241" | 2 | 1670551C1 |
| SPACER, PINION BEARING .243" | 2 | 1670553C1 |
| SET, BEARING SPACER DIFFERENTIAL PINION GEAR | 1 | 1694539C91 |
| SPACER, PINION BEARING 6.20MM/.244 IN | 2 | 2613360C1 |
| SPACER, PINION BEARING .242" | 2 | 1670552C1 |
| SPACER, PINION BEARING .209" | 2 | 1669540C1 |
| SPACER, PINION BEARING .210" | 2 | 1669541C1 |
| SPACER, PINION BEARING .211" | 2 | 1669542C1 |
| SPACER, PINION BEARING .212" | 2 | 1669543C1 |
| SPACER, PINION BEARING .213" | 2 | 1669544C1 |
| SPACER, PINION BEARING .217" | 2 | 1669545C1 |
| SPACER, PINION BEARING .220" | 2 | 1669546C1 |
| SPACER, PINION BEARING .224" | 2 | 1669547C1 |
| SPACER, PINION BEARING .228" | 2 | 1670547C1 |
| SPACER, PINION BEARING .232" | 2 | 1670548C1 |
| SPACER, PINION BEARING .236" | 2 | 1670549C1 |
| SPACER, PINION BEARING .240" | 2 | 1670550C1 |
| SEAL, SHIFT MOTOR TO CARRIER | 1 | 1696235C1 |
| PLUG | 1 | 1670503C1 |
| SPACER, HELICAL GEAR BEARING | 1 | 1670502C1 |
| WASHER, COMPANION FLANGE NUT | 1 | 1696377C1 |
| WASHER CARRIER TO HOUSING BOLT | 12 | 449671R1 |
| WASHER, THRUST DIFFERENTIAL SPIDER GEAR | 4 | 72335R1 |
| WASHER, THRUST | 2 | 2613377C1 |
| WASHER, FLAT PINION SHAFT WITH NUT 3" O.D. X 1.78" I.D. X .19" THICK | 1 | 264663C1 |
| RING ,O CARRIER IAD BORE | 1 | 2613494C1 |
| WASHER, FLAT | 1 | 1670499C1 |
| WASHER, BOLT BEARING CAP | 8 | 483361C1 |
| WASHER, FLAT | 10 | 2500348C1 |
| CUP, BEARING PINION INNER | 1 | 2613362C1 |
| CUP, BEARING INPUT SHAFT | 1 | 2613356C1 |
| CUP BEARING MAIN DIFFERENTIAL | 2 | 2613365C1 |
| CUP, BEARING REAR SIDE | 1 | 2613355C1 |
| CONE, BEARING PINION INNER | 1 | 2613359C1 |
| CONE, BEARING PINION INNER | 1 | 2613363C1 |
| GEAR, DRIVE | 1 | 2613348C1 |
| BEARING, THRUST INPUT SHAFT | 1 | 2613347C1 |
| PLUG, CAP SCREW CYLINDER COVER | 1 | 2613505C1 |
| RING LOCK DIFFERENTIAL ADJUSTER | 2 | 2613563C1 |
| LOCK, INPUT SHAFT ADJUSTER RING | 1 | 2613341C1 |
| SCREW DIFFERENTIAL LOCK COVER | 4 | 2613506C1 |
| BOLT, DIFFERENTIAL CARRIER BEARING CAP | 4 | 1696376C1 |
| WASHER, FLAT BEARING CAP | 4 | 1670535C1 |
| COVER DIFFERENTIAL WITH PUMP | 1 | 2613334C1 |
| COVER ASSEMBLY COMPLETE W/PUMP | 1 | 2613332C91 |
| CARRIER CAP ASSEMBLY 20K WITH DIFFERENTIAL LOCK | 1 | 2613324C91 |
| FORK DIFFERENTIAL LOCK | 1 | 2613384C1 |
| GEAR SET DIFFERENTIAL F/R 4.11 HYP 14X | 1 | 2613282C91 |
| WASHER, FLAT METRIC | 4 | 1696027C1 |
| GEAR, DRIVEN | 1 | 2613361C1 |
| FORK DIFFERENTIAL SHIFT | 1 | 2613327C1 |
| BOLT, SHIFT CYLINDER | 1 | 1696236C1 |
| BOLT | 16 | 1685290C1 |
| BOLT, DRIVE GEAR | 12 | 1670534C1 |
| NUT, HEXAGON LOCK PINION | 1 | 1685173C1 |
| NUT, HEXAGON LOCK METRIC | 12 | 1691622C1 |
| SPIDER DIFFERENTIAL | 1 | 2611289C1 |
| SPIDER INTERMEDIATE AXLE DIFFERENTIAL WITH PUMP | 1 | 2613351C1 |
| CAP SCREW | 10 | MS2120352 |
| COVER DIFFERENTIAL LOCK | 1 | 2613388C1 |
| HARNESS DCDL | 1 | 2611283C91 |
| SWITCH DCDL | 1 | 2611282C91 |
| CASE INTERMEDIATE AXLE DIFFERENTIAL | 1 | 2519528C91 |
| CASE INTERMEDIATE AXLE DIFFERENTIAL | 1 | 2613352C1 |
| DIFFERENTIAL CASE PLAIN HALF WITH DIFFERENTIAL LOCK | 1 | 2613373C1 |
| DIFFERENTIAL CASE FLANGE HALF 3.42-4.11 | 1 | 2613370C1 |
| COLLAR DIFFERENTIAL LOCK CLUTCH | 1 | 2613367C1 |
| COLLAR, SHIFT TRANSFER CASE | 1 | 3107S1397 |
| COLLAR, SHIFT TRANSFER CASE | 1 | 2596999C1 |
| SCREW, OIL BAFFLE /PUMP COVER | 8 | 2613336C1 |
| VALVE, RELIEF | 1 | 1685730C1 |
| RING, SNAP | 1 | 1670296C1 |
| SPRING, INPUT SHAFT THRUST | 1 | 1670524C1 |
| SPRING, SHIFT FORK | 1 | 1696233C1 |
| ROD PUSH DIFFERENTIAL LOCK | 1 | 2613329C1 |
| ROD PUSH DIFFERENTIAL LOCK | 1 | 2613389C1 |
| GEAR, REAR SIDE INTERMEDIATE AXLE | 1 | 2613353C1 |
| GEAR, SIDE 2.10-41 SPLINE | 2 | 2613483C1 |
| GEAR, HELICAL PINION SHAFT | 4 | 1676580C1 |
| GEAR, SPIDER DIFFERENTIAL | 4 | 1694558C1 |
| PISTON DIFFERENTIAL SHIFT | 1 | 2613346C1 |
| BEARING, NEEDLE INPUT SHAFT | 2 | 2613345C1 |
| END, TANDEM FORWARD R- WHEEL 2.10-41 SPLINE 342-411 RATIO WITH DCDL | 1 | 2613447C1 |
| END WHEEL TANDEM FORWARD | 1 | 2510333C1 |
| RING ADJUSTING MAIN DIFFERENTIAL | 2 | 2613364C1 |
| RING, ADJUSTING INPUT SHAFT | 1 | 2613331C1 |
| PLUG, CAP SCREW | 1 | 2613386C1 |
| SHAFT, INPUT | 1 | 2613344C1 |
| ASSEMBLY DIFFERENTIAL COVER | 1 | 2510330C91 |
CROSS REFERENCES
- MERITOR A13200N2224411
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
