2233804C93
WINDOW, PASS SPLIT SASH ASSEMBLY STANDARD WITH 5IN OPN BK TEMPERATURE 28%TINT
IC Bus
BACK ORDERED
Please contact us for information on lead time
$229.95
$275.94
This truck part is made by IC Bus. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
WINDOW, PASS SPLIT SASH ASSEMBLY STANDARD WITH 5IN OPN BK TEMPERATURE 28%TINT
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| FR, WINDOW BOTTOM FIXED EXTRUDED ALUMINUM | 1 | 2205208C5 |
| SCREW 1" | 12 | 2209431C1 |
| STOP, WINDOW OPENING | 2 | 2205674C2 |
| SCREW, FLAT HEAD COUNTERSUNK TYPE AB #6 X 3/4" | 2 | 91307100 |
| GLAZING, TEMPERED WINDOW | 1 | 2205498C2 |
| EXTRUSION, ALUMINUM WINDOW FIXED FR SIDE L BK | 1 | 2234062C1 |
| EXTRUSION, ALUMINUM WINDOW FIXED FR SIDE R BK | 1 | 2234063C1 |
| EXTRUSION, ALUMINUM WINDOW FIXED FR MIDDLE STANDARD BLACK | 1 | 2234617C91 |
| FR, WINDOW TOP FIXED EXTRUDED ALUMINUM | 1 | 2205216C3 |
| EXTRUSION, ALUMINUM WINDOW SLIDING FR TOP BK STANDARD | 1 | 2234048C1 |
| EXTRUSION, ALUMINUM WINDOW SLIDING FR SIDE BK | 2 | 2234043C2 |
| EXTRUSION, ALUMINUM WINDOW SLIDING FR BOT BK STANDARD | 1 | 2234038C3 |
| GLASS, TEMPERED SPLIT SASH WINDOW | 2 | 2209530C1 |
