3512958C91
TANK, FUEL 100 GALLON
Navistar International®
AVAILABLE
9 are currently available
Ships within 6-8 business days
$2,399.95
$2,879.94
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
RELATED PARTS
SPECIFICATIONS
VMRS
044-001-000
OEM Description
TANK FUEL SAFETY MDM 100 GAL
Weight
241.5 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| COVER FUEL TANK GAUGE HOLE | 1 | 336024C1 |
| GASKET 5 HOLE GAUGE | 1 | 464751C3 |
| GASKET 5 HOLE GAUGE | 1 | 345253C1 |
| FITTING, PLUG 1/2" NPT | 1 | 444631 |
| BREATHER FUEL TANK | 1 | 1698149C1 |
| PLUG, 3/4-14 ZNP H/HD AUTOMATIC PIP | 1 | 444637 |
| OUTLET, FUEL TANK | 1 | 1699761C1 |
| FITTING, CAP 1/2" | 1 | 2506455C1 |
| FITTING, CAP 3/8" | 1 | 2506454C1 |
| NECK, FUEL TANK FILLER | 1 | 2032014C1 |
| CAP, FUEL TANK FILLER NON LOCKING | 1 | 2507261C1 |
CROSS REFERENCES
- BORGWAR 3-0713
- BORGWAR 3-0713
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
