3597268F91
HARNESS ENGINE, AUTOMATIC TRANSMISSION HARNESS, ALLISON LCT
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$649.95
$779.94
FINAL SALE. No returns or exchanges.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
HARNESS ENGINE, AUTOMATIC TRANSMISSION HARNESS, ALLISON LCT
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| CONNECTOR, BODY 20 WAY SEALED FEMALE | 1 | 3522537C91 |
| TERMINAL, CABLE FEMALE 100 WATT | 54 | 3517243C1 |
| CONNECTOR, BODY PACKARD 100W SERIES 32-WAY (RED) | 1 | 3541172C91 |
| PLUG, SEALING 100 WATT | 31 | 3518314C1 |
| CONNECTOR, BODY PACKARD 100W SERIES 32-WAY (GRAY) | 1 | 3541171C91 |
| CONNECTOR, BODY 12 WAY PACKARD | 1 | 3589739C1 |
| TERMINAL, CABLE CONN TERMINAL | 2 | 3534163C1 |
| TERMINAL, CABLE CONN TERMINAL | 2 | 3534162C1 |
| TERMINAL, CABLE CONN TERMINAL | 7 | 3535303C1 |
| PLUG, SEALING CABLE TERMINAL YELLOW 5.8 MM | 2 | 3535427C1 |
| PLUG, SEALING CABLE TERMINAL BLUE | 7 | 3535424C1 |
| CONNECTOR, BODY 8 WAY FEMALE | 1 | 3525874C1 |
| TERMINAL, CABLE SEALED MALE | 4 | 1667742C1 |
| PLUG, SEALING CABLE WHITE | 2 | 3568570C1 |
| SEAL, CABLE TERMINAL LOOSE | 3 | 1661872C1 |
| CONNECTOR, BODY 24 WAY MALE | 1 | 3562312C1 |
| TERMINAL, CABLE 20-18 GAUGE | 1 | 3562314C1 |
| CONNECTOR, TYPE 104 2 WAY | 3 | 3594124C91 |
| TERMINAL, CABLE FEMALE | 6 | 3554322C1 |
| PLUG, SEALING GREEN | 6 | 3554318C1 |
| CONNECTOR, CABLE 2 WAY MALE | 1 | 3512967C1 |
| TERMINAL, CABLE FEMALE | 2 | 1661708C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
