3541071C94
HARNESS, ENGINE V8, AIR, 4AWG
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$1,949.95
$2,339.94
FINAL SALE. No returns or exchanges.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
HARNESS, ELECTRICAL ENGINE WIRING
Weight
25.0008 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| CONNECTOR, BODY 60 WAY W/BOLT | 1 | 2041416C2 |
| TERMINAL, CABLE SPADE | 1 | 366817C2 |
| TERMINAL, CABLE | 1 | 338892C2 |
| TERMINAL, CABLE | 3 | 365685C2 |
| TERMINAL, ELECTRICAL | 3 | 365682C2 |
| TERMINAL, BATTERY CABLE 4 GAUGE 13.5 MM | 2 | 578894C1 |
| CONNECTOR, BODY 1 WAY FEMALE | 1 | 587565C91 |
| TERMINAL, CABLE MALE WEATHERPACK 14,16 GAUGE | 1 | 587577C1 |
| CONNECTOR, BODY 1 WAY MALE | 2 | 587566C91 |
| CONNECTOR, CABLE | 1 | 1689462C1 |
| TERMINAL, CABLE TRACTION CONTROL 14 GAUGE | 2 | 1689464C1 |
| CONNECTOR, BODY 2 WAY FEMALE | 2 | 587567C91 |
| TERMINAL, CABLE CABLE FEMALE WEATHERPACK (GAUGE-18,20) | 2 | 587576C1 |
| CONNECTOR, BODY 6 WAY MALE | 1 | 587574C91 |
| TERMINAL, CABLE CABLE FEMALE WEATHERPACK (GAUGE-12) | 3 | 1673747C1 |
| PLUG, SEALANT LOOSE PIECE | 3 | 589390C1 |
| CONNECTOR, RECTIFIER SEALED MALE 2 WAY | 1 | 2031522C1 |
| TERMINAL, CABLE SEALED FEMALE | 2 | 2031531C1 |
| SEAL, CABLE TERMINAL | 2 | 2025426C1 |
| CONNECTOR, BODY 2 WAY SEALED FEMALE | 1 | 2031520C1 |
| CONNECTOR, CABLE 6 WAY | 1 | 2005240C1 |
| TERMINAL, CABLE TERMINAL SOCKET | 4 | 1680205C1 |
| TERMINAL, CABLE 14 GAUGE | 1 | 2033816C1 |
| CONNECTOR, BODY 1 WAY MALE | 1 | 1664531C1 |
| CONNECTOR, CABLE | 1 | 2036585C1 |
| TERMINAL, CABLE | 2 | 2036586C1 |
| CONNECTOR, CABLE | 1 | 2036584C1 |
| CONNECTOR, BODY SEALED RELAY | 3 | 3512331C91 |
| TERMINAL, CABLE SEALED TANGLESS | 6 | 3512334C1 |
| TERMINAL, CABLE SEALED 280 SERIES | 6 | 2039343C1 |
| CONNECTOR, BODY MAXI FUSE HOLDER W/MOUNTING TABS | 1 | 3525613C1 |
| TERMINAL, CABLE MAXIFUSE HOLDER (8 AWG) | 2 | 3525614C1 |
| SEAL | 1 | 3515525C1 |
| SEAL, CABLE TERMINAL BLUE | 1 | 3541256C1 |
| TERMINAL, CABLE, EYELET 3/8 STUD | 1 | 365680C2 |
| TERMINAL, CABLE 4 GAUGE 90 DEGREE | 1 | 3541078C1 |
| CONNECTOR, BODY 22 WAY MALE | 1 | 598332C1 |
| TERMINAL, CABLE CABLE MALE WEATHERPACK (GAUGE-12) | 2 | 1673748C1 |
| TERMINAL, CABLE CABLE MALE WEATHERPACK (GAUGE-18,20) | 5 | 587578C1 |
| TERMINAL, BATTERY CABLE 4 GAUGE 7.5 MM DIAMETER | 1 | 571673C1 |
| TERMINAL, CABLE | 10 | 2041420C1 |
| TERMINAL, CABLE | 32 | 2041419C1 |
| CONNECTOR, BODY 44-WAY PLUG | 1 | 3534349C1 |
| TERMINAL, CABLE 14-18 GAUGE | 37 | 3534360C1 |
| CONNECTOR, CABLE 3 WAY MALE | 1 | 1667741C1 |
| TERMINAL, CABLE FEMALE SEALED | 3 | 1661875C1 |
| SEAL, CABLE TERMINAL LOOSE | 3 | 1661872C1 |
| CONNECTOR, BODY 2 WAY MALE | 3 | 1671610C1 |
| TERMINAL, CABLE 16 GAUGE | 5 | 2033819C1 |
| PLUG, SEALANT | 44 | 1652325C1 |
| TERMINAL, BATTERY CABLE | 3 | 581156C1 |
| CONNECTOR, BODY 3 WAY MALE | 3 | 587570C91 |
| TERMINAL, CABLE FEMALE WEATHERPACK 14,16 GAUGE | 8 | 587575C1 |
| PLUG, SEALANT LOOSE PIECE | 6 | 589391C1 |
| TERMINAL, CABLE 5/16" DIAMETER EYELET | 1 | 2015884C1 |
| CONNECTOR, BODY 2 WAY MALE | 5 | 587568C91 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
