3522222C91
HARNESS MAIN WIRING*TRANSMISSI
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$969.95
$1,163.94
FINAL SALE. No returns or exchanges.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
HARNESS, ELECTRICAL MAIN WIRING TRANSMISSION
Weight
1.9998 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| CONNECTOR, CABLE | 3 | 2036583C1 |
| CONNECTOR, BODY 1 WAY FEMALE | 1 | 587565C91 |
| TERMINAL, CABLE CABLE MALE WEATHERPACK (GAUGE-18,20) | 1 | 587578C1 |
| PLUG, SEALANT | 4 | 1652325C1 |
| CONNECTOR, BODY 2 WAY MALE | 1 | 587568C91 |
| TERMINAL, CABLE CABLE FEMALE WEATHERPACK (GAUGE-18,20) | 2 | 587576C1 |
| TERMINAL, CABLE | 6 | 2036586C1 |
| CONNECTOR, BODY 31 WAY RECEPTACLE | 1 | 3536884C1 |
| TERMINAL, CABLE TERMINAL PIN | 28 | 1680206C1 |
| PLUG, SEALING | 15 | 453133C1 |
| CONNECTOR, BODY 31 WAY | 1 | 3508926C1 |
| TERMINAL, CABLE | 19 | 3508927C1 |
| CONNECTOR, BODY 1 WAY MALE | 1 | 587566C91 |
| CONNECTOR, CABLE 2 WAY FEMALE | 1 | 1684260C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
