3590373C91
HARNESS, ELECTRICAL MAIN WIRING HYDRAULIC BRAKES
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$259.95
$311.94
FINAL SALE. No returns or exchanges.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
RELATED PARTS
SPECIFICATIONS
OEM Description
HARNESS, ELECTRICAL MAIN WIRING HYDRAULIC BRAKES
Weight
14.26 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| BLOCK, FUSE | 1 | 1659650C1 |
| TERMINAL, CABLE TERMINAL FEMALE | 1 | 557380C1 |
| TERMINAL, CABLE FEMALE DOUBLE FEED | 2 | 1661390C1 |
| TERMINAL, CABLE RING | 1 | 365679C2 |
| TERMINAL, CABLE | 1 | 365683C2 |
| CONNECTOR, CABLE MALE | 1 | 598839C1 |
| TERMINAL, ELECTRICAL JUNCTIONS | 2 | 188396R1 |
| TERMINAL, CABLE FEMALE 56 SERIES | 1 | 879633R1 |
| CONNECTOR, BODY 2 WAY MALE | 1 | 587568C91 |
| TERMINAL, CABLE CABLE FEMALE WEATHERPACK (GAUGE-18,20) | 2 | 587576C1 |
| PLUG, SEALANT | 2 | 1652325C1 |
| CONNECTOR, BODY 1 WAY MALE NATURAL | 1 | 188395R1 |
| TERMINAL, CABLE FEMALE | 1 | 2022374C1 |
| CONNECTOR, CABLE TO PLUG | 1 | 3517441C1 |
| TERMINAL, CABLE MALE | 1 | 3517439C1 |
| CONNECTOR, BODY 10 WAY WHITE | 1 | 3530564C1 |
| TERMINAL, CABLE | 1 | 3541250C1 |
| TERMINAL, CABLE FEMALE | 7 | 1661224C1 |
| TERMINAL, CABLE FEMALE | 6 | 1661710C1 |
| CONNECTOR, BODY 10 WAY BLACK | 1 | 3530563C1 |
| CONNECTOR, CABLE 3 WAY MALE | 1 | 1667741C1 |
| TERMINAL, CABLE FEMALE SEALED | 2 | 1661875C1 |
| PLUG, SEALING CABLE WHITE | 2 | 3568570C1 |
| CONNECTOR, CABLE 1 WAY FEMALE | 2 | 239808R1 |
| TERMINAL, CABLE CABLE*FEMALE (250 FASTON) W/TANG | 2 | 239805R1 |
| CONNECTOR, CABLE 6 WAY | 1 | 1687790C1 |
| TERMINAL, CABLE FEMALE 16,18,20 GAUGE | 5 | 1651943C1 |
| CONNECTOR, CABLE | 1 | 293347C1 |
| TERMINAL, CABLE FEMALE 3 MM | 1 | 1660577C1 |
| TERMINAL, CABLE FEMALE | 1 | 879630R1 |
| CONNECTOR, BODY 2 WAY MALE | 1 | 1661777C1 |
| SEAL, CABLE TERMINAL LOOSE | 2 | 1661872C1 |
| CONNECTOR, BODY 17 WAY MALE | 1 | 1661601C1 |
| TERMINAL, CABLE FEMALE | 24 | 1661598C1 |
| CONNECTOR, BODY 17 WAY | 1 | 1661602C1 |
| SOCKET, LIGHT | 5 | 2001688C1 |
| TERMINAL, CABLE WEDGE BASE SOCKET 16, 18 GAUGE | 10 | 2001704C1 |
| CONNECTOR, BODY 3 WAY | 1 | 1661891C1 |
| TERMINAL, CABLE FEMALE SINGLE FEED | 7 | 1661395C1 |
| TERMINAL, CABLE MALE | 3 | 1661262C1 |
| CONNECTOR, BODY 1 WAY FEMALE | 1 | 1661202C1 |
| CONNECTOR, BODY 3 WAY FEMALE | 1 | 1661198C1 |
| CONNECTOR, BODY 6 WAY MALE | 1 | 1661200C1 |
| CONNECTOR, CABLE MALE | 1 | 872291R1 |
| CONNECTOR, CABLE | 3 | 892136C1 |
| CONNECTOR, BODY FEMALE | 1 | 3544066C1 |
| TERMINAL, CABLE PIN CONTACT | 2 | 1659750C1 |
| TERMINAL, CABLE SOCKET #16 | 5 | 1651968C1 |
| TERMINAL, F TERMINAL | 1 | 879632R1 |
| CONNECTOR, CABLE MALE | 1 | 2005835C1 |
| TERMINAL, CABLE FEMALE | 2 | 1661209C1 |
| CONNECTOR, BODY | 1 | 593385C1 |
| CONNECTOR, BODY MAXI FUSE HOLDER W/MOUNTING TABS | 1 | 3525613C1 |
| TERMINAL, CABLE MAXIFUSE HOLDER (8 AWG) | 2 | 3525614C1 |
| SEAL | 2 | 3515525C1 |
| TERMINAL, RING TERMINAL | 2 | 480417C1 |
| CONNECTOR, BODY | 1 | 2009385C1 |
| CONNECTOR, BODY 10 WAY | 1 | 1654231C1 |
| TERMINAL, CABLE PIN CONTACT FEMALE | 5 | 1659927C1 |
| TERMINAL, CABLE 18,20 GAUGE | 2 | 3507202C1 |
| CONNECTOR, BODY 12 WAY | 1 | 3553404C1 |
| TERMINAL, CABLE TERMINAL SOCKET, SIZE 20 | 13 | 3518963C1 |
| TERMINAL, CABLE | 1 | 3555249C1 |
| CONNECTOR, BODY 12 WAY | 1 | 3586750C1 |
| TERMINAL, CABLE FEMALE | 3 | 2018946C1 |
| TERMINAL, CABLE FEMALE | 3 | 1659673C1 |
| CONNECTOR, CABLE NATURAL FEMALE | 1 | 188393R1 |
| TERMINAL, CABLE CABLE MALE PACKARD 56 SERIES | 1 | 241117R1 |
| TERMINAL, CABLE FEMALE SINGLE FEED | 3 | 1661392C1 |
| TERMINAL, CABLE FEMALE SINGLE FEED | 16 | 1661389C1 |
| TERMINAL, CABLE FEMALE TRIPLE FEED | 3 | 1661391C1 |
| TERMINAL, CABLE FEMALE TRIPLE FEED | 1 | 1661397C1 |
| TERMINAL, CABLE FEMALE DOUBLE FEED | 3 | 1661396C1 |
| TERMINAL, CABLE FEMALE | 20 | 1661709C1 |
| CONNECTOR, BODY 45 WAY | 1 | 1661193C1 |
| TERMINAL, CABLE FEMALE | 9 | 1661208C1 |
| TERMINAL, CABLE FEMALE MINIFUSE | 1 | 3566715C1 |
| TERMINAL, CABLE FEMALE SINGLE FEED | 2 | 1661386C1 |
| TERMINAL, CABLE FEMALE | 8 | 1661215C1 |
| TERMINAL, CABLE FEMALE | 2 | 1661219C1 |
| TERMINAL, CABLE FEMALE | 8 | 1661218C1 |
| TERMINAL, CABLE FEMALE | 1 | 1661227C1 |
| TERMINAL, CABLE FEMALE | 3 | 1661226C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
