4041248C2
SUPPORT FUEL TANK MOUNTING ASSEMBLY R
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$81.95
$98.34
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
SUPPORT FUEL TANK MOUNTING ASSEMBLY R
Weight
5 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| SUPPORT FUEL TANK MOUNTING FACE | 1 | 4042860C1 |
| SUPPORT FUEL TANK MOUNTING LEG R | 1 | 4044284C1 |
| SUPPORT FUEL TANK MOUNTING REINFORCEMENT | 1 | 4041240C1 |
| BOLT, FLANGE HEAD M10 X 3 | 2 | 3549305C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
