4080344C91
SEAT, DRIVER, SLP CAB, CLOTH, HP AIR, BELLOWS, GRAY
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$1,899.95
$2,279.94
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
SEAT, DRIVER, SLP CAB, CLOTH, HP AIR, BELLOWS, GRAY
Weight
110 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| UPHOLSTERED CUSHION, CHARCOAL/BLACK CLOTH VINYL | 1 | 2516492C91 |
| SUPPORT, SEAT AIR LUMBAR | 1 | 1697099C1 |
| UPHOLSTERED ARMREST LEFT HAND | 1 | 2516553C91 |
| UPHOLSTERED ARMREST RIGHT HAND | 1 | 2516552C91 |
| COVER, ARMREST RIGHT HAND | 1 | 2516556C1 |
| COVER, ARMREST LEFT HAND | 1 | 2516557C1 |
| VALVE, HIGH PRESSURE AIR RED HANDLE | 1 | 2505475C1 |
| VALVE, LOW PRESSURE AIR GRAY HANDLE | 1 | 2505476C1 |
| MANIFOLD, SEAT FOUR BUTTON | 1 | 2505477C1 |
| KIT, AIR SPRING | 1 | 2595130C91 |
| COVER, SEAT CUSHION, BLACK CLOTH AND VINYL | 1 | 2516504C1 |
| UPHOLSTERED BACK | 1 | 2516569C1 |
| COVER, SEATBACK, CHARCOAL, BLACK CLOTH AND VINYL | 1 | 2516537C1 |
| PEDESTAL, SEAT | 1 | 2510995C91 |
| ABSORBER, SHOCK ABSORBER SEAT | 1 | 2594712C91 |
| FR, SEAT LOWER | 1 | 2594756C1 |
| FRAME, SEAT BACK | 1 | 2597791C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
