3674498C91
SEAT,OCCUPANT, SEATS INC. 911
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$659.95
$791.94
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
SEAT OCCUPANT SEATS INC. 911
Weight
104.0006 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| ABSORBER, SHOCK ABSORBER SEAT | 1 | 2597441C1 |
| BACK, SEAT DRIVER | 1 | 2597444C1 |
| COVER, CUSHION BACK Y | 1 | 2597443C1 |
| TRACK, ADJUSTER SEAT | 1 | 2597439C1 |
| PEDSTAL, SUSPENSION SEAT | 1 | 2594876C91 |
| KNOB, LUMBAR SEAT W/PIN | 1 | 2597440C1 |
| KNOB, RECLINER SEAT W/HARDWARE | 1 | 2597445C1 |
| KNOB, RECLINER SEAT | 1 | 2597447C1 |
| VALVE, AIR CONTROL SEAT | 1 | 2594878C1 |
| SPRING, AIR SEAT | 1 | 2592879C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
