3662505C92
SEAT, DRIVER NAT 2000 HIGH BACK, AIR, TAN CLOTH
Navistar International®
IN STOCK
More than 10 are currently available
Ships within 1 business day
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
This driver's seat is designed with high back support and is crafted from tan cloth material, providing both comfort and style. The high back design offers excellent support for the back and neck, making it ideal for long drives. The seat is designed with high-quality materials that ensure longevity and resistance to wear and tear. Additionally, the seat's construction includes ample cushioning and ergonomic contours that promote a healthy posture, enhancing the overall driving experience.
Navistar International Corporation has been a trusted name in the automotive industry for over a century, renowned for its commitment to quality and innovation. The driver's seat designed with high back support is a prime example of the company’s dedication to enhancing driver comfort. Crafted from durable materials, this seat ensures longevity and resistance to wear and tear, making it ideal for daily use. The ergonomic design promotes a healthy posture, while the adjustable features allow for a personalized fit. By focusing on driver comfort and functionality, Navistar helps improve the overall driving experience, ensuring that operators can focus on the road ahead.
- - 9200 Premium Conventional (built before 3/15/96)
- - 5600I Severe Service Conventional
- - 9900 Premium Conventional (built on or after 3/15/96)
- - 5500I Severe Service Conventional
- - 5900I Severe Service Conventional
Models:
When you choose Source One Parts Center, you are opting for a company that values integrity and transparency in every transaction. We provide all the information necessary to make informed decisions.
SPECIFICATIONS
BILL OF MATERIALS
Name | Quantity | Part Number |
---|---|---|
FRAME, SEAT BACK | 1 | 2597791C1 |
BRACKET, MOUNTING SEAT PEDESTAL | 1 | 2505006C1 |
BRACKET, SEAT RECLINE LIMITING | 1 | 2590579C91 |
BOLT, SPECIAL BACKREST ADJUSTER KNOB | 1 | 1685452C1 |
FR, SEAT LOWER | 1 | 2508970C1 |
FR, LOWER SEAT | 1 | 2586959C1 |
SUPPORT, CHUGGER | 1 | NS22972301 |
BEARING, ROLLER ASSEMBLY CHUGGER SEAT | 4 | 1685465C1 |
NUT AND WASHER ASSEMBLY 5/16-18 | 2 | NS22815201 |
KNOB, SEAT TRACK | 1 | 2505380C1 |
STUD, TRACK | 4 | 2502303C1 |
PEDESTAL, SEAT | 1 | 2505381C91 |
REST ARM RIGHT HAND | 1 | 2606836C1 |
BUMPER, SEAT STOP | 1 | 2505384C1 |
ARM ASSEMBLY UPPER W/BUSHINGS | 1 | 2505385C1 |
REST ARM LH | 1 | 2606835C1 |
ABSORBER, SHOCK ABSORBER SEAT | 1 | 507831C91 |
RETAINER, SEAT AIR SPRING | 1 | 1685464C1 |
ELBOW, HOSE CONNECTOR 90 DEGREE | 1 | 571156C1 |
RING, SNAP | 4 | 544968R1 |
BRACKET, SEAT BELT MOUNTING | 1 | 2505859C1 |
BUSHING, SEAT ARM SPACER | 8 | 2505470C1 |
ELBOW, 90 DEGREE BARBED | 3 | NS18002753 |
SUPPORT, SEAT AIR LUMBAR | 1 | 1697099C1 |
BASE, MOUNTING SEAT LOWER | 1 | 2505382C1 |
NUT, 5/16-18 LOCK | 1 | NS17706049 |
BASE, DRIVER SEAT MOUNTING SWIVEL | 1 | 2505383C1 |
VALVE, HIGH PRESSURE AIR RED HANDLE | 1 | 2505475C1 |
MANIFOLD, SEAT SIX BUTTON | 1 | 2505474C1 |
BUMPER SEAT BACK PROTECTOR | 1 | 2606458C1 |
CROSS REFERENCES
- NATL ST 50700
- NATL ST 50700
- NATL ST 50700.14BG321
- NATL ST 50700.14BG321
