3570856C93
SEAT, DRIVER HIGH BACK, AIR, TAN CLOTH, SWIVEL ,16JPL,SLP
Navistar International®
AVAILABLE
4 are currently available
Ships within 6-8 business days
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
This driver seat features a high back design with air suspension, crafted from tan cloth for maximum comfort. The seat is engineered to provide excellent lumbar support, promoting good posture during extended periods of driving. Its adjustable features allow for a personalized fit, catering to individual preferences and enhancing the overall driving experience. The stylish appearance complements the interior of any vehicle, while the robust construction ensures it can withstand daily wear and tear. The seat is also designed for easy installation, making it a practical choice for those looking to upgrade their vehicle's interior.
Navistar International Corporation has a storied history of excellence in vehicle manufacturing, with a focus on producing high-quality components that enhance the driving experience. The company's reputation for reliability and performance is well-established, making it a trusted choice for commercial operators. This high back driver seat features advanced air suspension technology, providing optimal comfort and support. The tan cloth upholstery adds a touch of style, while the adjustable features allow drivers to customize their seating position. By prioritizing driver comfort and functionality, Navistar continues to lead the way in creating seating solutions that enhance the overall driving experience.
- - 9200: Premium Conventional (built before 3/15/96)
- - 9400: Premium Conventional (after 3/15/96)
- - 5900: Severe Service Conventional
- - 9900: Premium Conventional (built on or after 3/15/96)
Models compatible with this part number include:
Our focus on quality means that we only stock parts from trusted manufacturers. This attention to detail is what keeps our customers coming back time and time again.
SPECIFICATIONS
BILL OF MATERIALS
Name | Quantity | Part Number |
---|---|---|
FR, HIGH BACK SEAT | 1 | 2588939C1 |
BOLT, SPECIAL BACKREST ADJUSTER KNOB | 1 | 1685452C1 |
FR, SEAT LOWER | 1 | 2505378C1 |
SUPPORT, CHUGGER | 1 | NS22972301 |
BEARING, ROLLER ASSEMBLY CHUGGER SEAT | 4 | 1685465C1 |
NUT AND WASHER ASSEMBLY 5/16-18 | 2 | NS22815201 |
KNOB, SEAT TRACK | 1 | 2585791C1 |
STUD, TRACK | 4 | 2502303C1 |
PEDESTAL, SEAT | 1 | 2505381C91 |
BUMPER, SEAT STOP | 1 | 2505384C1 |
ARM ASSEMBLY UPPER W/BUSHINGS | 1 | 2505385C1 |
ABSORBER, SHOCK ABSORBER SEAT | 1 | 507831C91 |
RETAINER, SEAT AIR SPRING | 1 | 1685464C1 |
ELBOW, HOSE CONNECTOR 90 DEGREE | 1 | 571156C1 |
RING, SNAP | 4 | 544968R1 |
BRACKET, MOUNTING SEAT BELT | 1 | 2505469C1 |
BUSHING, SEAT ARM SPACER | 8 | 2505470C1 |
ELBOW, 90 DEGREE BARBED | 3 | NS18002753 |
CUSHION, HIGH BACK SEAT BACK TAN CLOTH | 1 | 2509553C91 |
COVER, SEAT CUSHION TAN CLOTH | 1 | 2601504C1 |
CUSHION, SEAT TAN CLOTH | 1 | 2509550C91 |
COVER BACK CUSHION HIGH TAN CLTH | 1 | 2601506C1 |
SUPPORT, SEAT AIR LUMBAR | 1 | 1697099C1 |
BASE, MOUNTING SEAT LOWER | 1 | 2505382C1 |
NUT, 5/16-18 LOCK | 1 | NS17706049 |
BASE, DRIVER SEAT MOUNTING SWIVEL | 1 | 2505383C1 |
VALVE, HIGH PRESSURE AIR RED HANDLE | 1 | 2505475C1 |
MANIFOLD, SEAT FOUR BUTTON | 1 | 2505477C1 |
BASE, DRIVER SEAT MOUNTING SWIVEL W/TAN HANDLE | 1 | 2508983C1 |
BRACKET, MOUNTING SEAT PEDESTAL | 1 | 2505006C1 |
BRACKET, SEAT RECLINE LIMITING | 1 | 2590579C91 |
CROSS REFERENCES
- NATL ST 50230
- NATL ST 50230
- NATL ST 50230.13BF321
- NATL ST 50230.13BF321
