3559774C91
SEAT, HIGH BACK PASSENGER GRAY MORDURA T905
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$599.95
$719.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
VMRS
002-037-002
OEM Description
SEAT, HIGH BACK PASSENGER GRAY MORDURA T905
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| BASE, PASSENGER SEAT MOUNTING | 1 | 1691495C1 |
| BASE, PASSENGER SEAT MOUNTING | 1 | 1697598C1 |
| SUPPORT, ASSEMBLY SEAT FOAM | 1 | 1697575C1 |
| CUSHION, SEAT FOAM | 1 | 2503288C1 |
| COVER, SEAT CUSHION SEAT BOTTOM GRAY MORDURA | 1 | 2503287C1 |
| CUSHION, HIGH BACK SEAT BACK FOAM W/COVER | 1 | 2503286C1 |
| COVER, HIGH BACK SEAT CUSHION SEAT BACK GRAY MORDURA | 1 | 2503285C1 |
| HANDLE, SEAT RECLINER ADJUSTABLE | 1 | 1699558C1 |
| KNOB, SEAT ADJUSTER TILT | 1 | 1693551C1 |
| KNOB, SEAT ADJUSTER TILT | 1 | 1697599C1 |
| PLATE, SEAT UPPER WELDMENT | 1 | 1697799C1 |
| FR, HIGH BACK SEAT | 1 | 2503266C1 |
CROSS REFERENCES
- BOSTROM 2340073-552
- BOSTROM 2340073-552
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
