3535588C92
SEAT, HIGH BACK DRIVER /PASSENGER AIR SUSPENSION GRAY MORDURA
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$489.95
$587.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
RELATED PARTS
SPECIFICATIONS
VMRS
002-037-002
OEM Description
SEAT, HIGH BACK DRIVER /PASSENGER AIR SUSPENSION GRAY MORDURA
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| FR, SEAT HIGH BACK | 1 | 1697571C1 |
| KNOB, ADJUSTABLE LUMBAR SEAT | 1 | 2500386C1 |
| HANDLE, SEAT ADJUSTABLE RECLINER | 1 | 2503746C1 |
| PLATE, SEAT UPPER WELDMENT | 1 | 2501476C1 |
| RISER, SEAT SUPPORT | 1 | 2504140C1 |
| COVER, SEAT CUSHION SEAT BOTTOM GRAY CORDURA | 1 | 2508478C1 |
| PAD, SEAT CUSHION | 1 | 1699241C1 |
| KIT, MECHANICAL LUMBAR SEAT | 1 | 1697573C91 |
| KIT, BACK STOP RESTRICTION | 1 | 573787C91 |
| KIT, SEAT PAN SUPPORT | 1 | 2501472C91 |
| KIT, SEAT ARMREST INSERT | 1 | 2501473C91 |
| KIT, SEAT ARMREST BRACKET | 1 | 2501474C91 |
| KIT, SEAT MOUNTING HARDWARE | 1 | 1691516C91 |
| SEAT ICP BRACKET | 1 | 1691496C91 |
| KIT SEAT ADJUSTER HEIGHT VALVE TGGL TYP | 1 | B6222207001 |
| KIT SEAT ADJUSTER HEIGHT VALVE TGGL TYP | 1 | 2504120C91 |
| KIT, ISOLATOR SPRING SEAT | 1 | 1697577C91 |
| KIT, SEAT CONTROL HANDLE | 1 | 2508178C91 |
| KIT, SEAT TILT REPLACEMENT | 1 | 1697579C91 |
| KIT, SEAT SLIDE RAIL | 1 | 2501475C91 |
| LOW PROFILE SEAT ISOLATOR 9 1/2" | 1 | 1697581C92 |
| KIT, SEAT SUSPENSION HARDWARE | 1 | 1696110C91 |
| KIT, AIR SPRING 914/915/960/715E | 1 | 1696124C91 |
| KIT, SEAT LEVER ASSEMBLY | 1 | 2505095C1 |
| KIT, HEAVY DUTY SHOCK ABSORBER 915 | 1 | 1696117C91 |
| KIT, ADJUSTABLE SEAT RESTRICTION FORE/AFT | 1 | 1697591C91 |
| COVER, HIGH BACK SEAT CUSHION SEAT BACK GRAY CORDOVAN | 1 | 2504142C1 |
| PAD, HIGH BACK SEAT BACK CUSHION | 1 | 1698425C1 |
CROSS REFERENCES
- BOSTROM R352009-418
- BOSTROM R352009-418
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
