4105361C91
PANEL, SLEEPER MODESTY, SST ASSEMBLY WITH LEFT W/EXT LEFT HAND
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$519.95
$623.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
PANEL, SLEEPER MODESTY, SST ASSEMBLY WITH LEFT W/EXT LEFT HAND
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| PANEL, SLEEPER MODESTY, SST WITH LEFT W/EXT LEFT HAND | 1 | 4105357C1 |
| NUT, HEXAGON 1/4" UNC | 4 | 25458R1 |
| BUTTON, FASTENER CABLE LOCK | 4 | 3526024C2 |
| HARNESS, JUMPER, REAR MODESTY PANEL | 1 | 4105621C91 |
| WASHER, LOCK | 2 | 27303R1 |
| LIGHT, SIDE MARKER REFLEX | 4 | 4066933C1 |
| SCREW, MACHINE PAN HEAD #8-32 X 3/4" | 8 | 40226R1 |
| EXTENSION, CLIP | 4 | 3947262R1 |
| WASHER, LOCK | 8 | 27306R1 |
| NUT, HEXAGON MACHINE STAINLESS STEEL #8 UNC | 8 | 27296R1 |
| WASHER, FLAT | 8 | 178474 |
| BOLT 1/4" X 3/4" | 4 | 22728R1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
