4083579C95
DASH PANEL ASSEMBLY FOR REGULAR /CREW CAB WITH HYDROMAX
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$569.95
$683.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
DASH PANEL ASSEMBLY FOR REGULAR /CREW CAB WITH HYDROMAX
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| PANEL, ASSEMBLY- COWL SI LEFT HAND | 1 | 7500039C1 |
| ROUND HEAD, LARGE FLANGE WELD STUD | 5 | 7500042C1 |
| WELD STUD | 11 | 7500046C1 |
| LOWER BRACKET SUPPORT LEFT HAND SIDE ASSEMBLY | 1 | 4077700C1 |
| LOWER BRACKET SUPPORT RIGHT HAND SIDE ASSEMBLY | 1 | 4077701C1 |
| MIDDLE BRACKET SUPPORT LEFT HAND SIDE ASSEMBLY | 1 | 4077702C2 |
| MIDDLE BRACKET SUPPORT RIGHT HAND SIDE ASSEMBLY | 1 | 4077703C2 |
| DASH PANEL ASSEMBLY | 1 | 4080414C2 |
| FENDER EXTENSION SUPPORT ASSEMBLY | 2 | 4084553C2 |
| SURGE TANK BRACE ASSEMBLY | 1 | 4087303C2 |
| LARGE FLANGE, WELD STUD | 4 | 7500045C1 |
| PANEL, ASSEMBLY- COWL SI RIGHT HAND | 1 | 7500040C1 |
| HARNESS ROUTING SUPPORT ASSEMBLY | 1 | 4088159C2 |
| DASH PLENUM UPPER PANEL | 1 | 7500041C1 |
| BRAKE AND ACCELERATOR PEDAL REINFORCEMENT ASSEMBLY | 1 | 4087990C2 |
| DASH FRONT PLENUM LOWER PANEL DEFLECTOR | 1 | 7500049C1 |
| HEAD LESS WELD STUD | 15 | 7500038C2 |
| FRONT DASH PLENUM PANEL | 1 | 7500043C1 |
| LARGE FLANGE SURFACE WELD STUD | 11 | 7500035C1 |
| ROUND HEAD WELD STUD | 3 | 7500037C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
