3860311C2
PANEL, DOOR ASSY, LH, DK NEUTRAL POWER W/ MIRROR, TWE, EAGLE
Navistar International®
BACK ORDERED
Please contact us for information on lead time
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
PANEL, DOOR ASSY, LH, DK NEUTRAL POWER W/ MIRROR, TWE, EAGLE
Weight
9.0002 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| PANEL LEFT HAND POWER LOCK, WINDOW, MIRROR W/LIM, TWTR | 1 | 3670246C3 |
| PANEL L CLOTH DK NEUTRAL | 1 | 3722733C1 |
| BEZEL, TRIM LH WOODGRAIN | 1 | 3625970C2 |
| PANEL FRONT ARMREST TOPPER WITH POWER MIRROR L | 1 | 3625210C3 |
| PANEL LEFT FRONT ARMREST SKIRT | 1 | 3860277C1 |
| FASTENER, STUD RECEIVER THIN WALL | 17 | 3625214C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
