3811154C92
PANEL ASSEMBLY, DOOR AIR LINE CABINET
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$309.95
$371.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
RELATED PARTS
SPECIFICATIONS
OEM Description
PANEL ASSEMBLY, DOOR AIR LINE CABINET
Weight
16.03 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| PANEL- AIR LINE DOOR REAR INNER | 1 | 3812313C1 |
| SPACER BUMPER WARDROBE DOOR | 4 | 3809193C1 |
| SPACER, BUMPER AIR LINE DOOR | 2 | 3818709C2 |
| SCREW TYPE A THREAD #8-18 X .75 | 2 | 3614700C1 |
| PANEL AIR LINE CABINET DOOR OUTER REAR | 1 | 3807498C1 |
| REINFORCEMENT ASSEMBLY AIR LINE CABINET DOOR REAR | 1 | 3813839C1 |
| SUPPORT, STRUT BRACKET | 2 | 3802788C1 |
| LATCH, ACCESS DOOR AIR LINE CABINET | 1 | 3807499C1 |
| HINGE, DOOR AIR LINE CABINET | 3 | 3811038C1 |
| SCREW, PAN HEAD TORX | 13 | 3818458C1 |
| RIVET STEEL 3/16" | 3 | 3803071C1 |
| SCREW PAN HEAD TORX BLACK M 5 X 16MM | 12 | 3805951C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
