3768585C92
PANEL, LOWER FASCIA ASSEMBLY WITH TRACK, LEFT HAND, LONG
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$799.95
$959.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
PANEL, LOWER FASCIA ASSEMBLY WITH TRACK, LEFT HAND, LONG
Weight
30 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| PANEL, SIDE FASCIA W/SLOT LEFT HAND, LONG | 1 | 4068199C1 |
| LIGHT, OVER HEAD COMPARTMENT MAP LIGHT | 1 | 6103961C92 |
| NUT, PANEL M4.2 X 1.41 | 2 | 3599207C2 |
| PANEL SPEAKER GRILLE | 1 | 3859572C1 |
| SUPPORT SPEAKER BRACKET | 1 | 3860272C1 |
| SCREW #8 X 5/8 HEXAGON HEAD TYPE BP | 2 | 3868468C1 |
| SPEAKER, RADIO DUAL CONE 3 1/2" | 1 | 3520852C1 |
| HARNESS, JUMPER, MAP LIGHT | 1 | 6110337C91 |
| VISOR, SUN, LH | 1 | 3715187C3 |
| VISOR, SUN, CLIP- LEFT HAND | 1 | 3715185C2 |
| TRACK, CURTAIN WINDSHIELD LEFT HAND | 1 | 3715183C1 |
| PANEL OHC BIN LEFT HAND | 1 | 3857721C1 |
| FASTENER, SPRING CLIP | 11 | 3616801C1 |
| RIVET, BLIND BLACK | 4 | 3615442C1 |
| SCREW TORX PLASTIC 4.5 X 1.41 X 14MM | 4 | 3810516C2 |
| FASTENER, SPEED NUT PUSH ON | 1 | 3620595C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
