3728605C92
PANEL, OVER HEAD CONSOLE W/PREM W/TAKATA SAFE
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$529.95
$635.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
PANEL, OVER HEAD CONSOLE W/PREM W/TAKATA SAFE
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| PANEL, OVER HEAD CONSOLE | 1 | 3710181C3 |
| NET, OVER HD CONSOLE RESTRAINT | 2 | 3600019C1 |
| RETAINER RESTRAINT CORD | 1 | 3600014C1 |
| SPEAKER, RADIO DUAL CONE 3 1/2" | 2 | 3520852C1 |
| GRILLE, RADIO SPEAKER 3 1/2" | 2 | 3520853C1 |
| RETAINER, CB RADIO SPEAKER FASTENER | 2 | 3521569C1 |
| SCREW, SPECIAL TAPPING | 4 | 501725C1 |
| PANEL, SIDE CLOSEOUT L | 1 | 6106500C1 |
| CLIP, SUN VISOR ROD COOL GRAY LEFT HAND | 1 | 3599154C3 |
| CLIP, SUN VISOR ROD COOL GRAY LEFT HAND | 1 | 3599154C2 |
| PANEL, SIDE CLOSEOUT R | 1 | 6106501C1 |
| FASTENER, SPRING CLIP | 2 | 3616801C1 |
| CAP, OVER HEAD CONSOLE | 4 | 6109483C1 |
| CLIP, SUN VISOR ROD COOL GRAY RIGHT HAND | 1 | 3599155C2 |
| VISOR, SUN MEDIUM NEUTRAL LEFT HAND | 1 | 3615175C1 |
| VISOR, SUN MEDIUM NEUTRAL RIGHT HAND | 1 | 3615176C1 |
| BEZEL TRIM OVER HEAD CENTER CONSOLE ASSEMBLY W/LIGHTS | 1 | 3835431C91 |
| LIGHT, DOME | 1 | 3599755C2 |
| HARNESS, ROOF WIRING W/DAYCAB W/ANTENNA W/DUAL SPEAKER | 1 | 3710179C91 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
