3686088C91
PANEL ASSEMBLY, SKIRT SLEEPER FRONT CHROME
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$959.95
$1,151.94
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
PANEL ASSEMBLY, SKIRT SLEEPER FRONT CHROME
Weight
9.02 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| PANEL FRONT SLEEPER SKIRT LEFT HAND CHROMED | 1 | 3810165C1 |
| BEZEL, MARKER LIGHT | 4 | 3664103C1 |
| LIGHT, CLEARANCE AMBER LED | 4 | 3827821C91 |
| SCREW, PAN HEAD #10 X 3/4" | 8 | 27217R1 |
| NUT #10 UNC | 8 | 19910R1 |
| CLAMP RUBBER COVERED 9/16" | 4 | 98959R1 |
| HARNESS, LIGHTS MODESTY CAB MOUNTING | 1 | 3814236C92 |
| NUT, MULTIPLE THREAD M6 | 1 | 3569643C1 |
| PANEL CAB SKIRT RIGHT HAND CHRMD W/B-PLLR EXHAUST | 1 | 3686740C1 |
| STRAP, CABLE LOCK | 4 | 306132C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
