3926065C91
HOSE, AIR CONDITION ASSEMBLY COND TO EVAPORATOR 2010 I6 MID CAB
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$389.95
$467.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
HOSE, AIR CONDITION ASSEMBLY COND TO EVAPORATOR 2010 I6 MID CAB
Package Dimensions
20.5 x 13.0 x 3.2 in
Weight
1.82 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| O-RING SEAL 10 25/32" X 2 5/8" | 2 | 3543727C1 |
| CAP, SHIPPING, REFRIGERANT FITTING 1/2" MALE | 2 | 3555226C1 |
| SEAL, C- PLATE 1/2" | 2 | 3543881C1 |
| A/C FITTING #630 COND OUT TUBE ASSEMBLY 1/2 NOM OD | 1 | 3926071C1 |
| A/C FITTING, #327 EVAPORATOR IN TUBE | 1 | 3896768C1 |
| RING ,O HNBR 7.37 ID X 1.81 THK | 1 | 1693968C1 |
| CORE, VALVE AIR CONDITIONER HOSE | 1 | 2503677C1 |
| SWITCH, AIR CONDITIONER PRESSURE | 1 | 3546241C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
