3819196C91
HOSE ASSEMBLY, AIR CONDITIONER SUCTION LINE
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$179.95
$215.94
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
VMRS
001-002-000
OEM Description
HOSE ASSEMBLY, AIR CONDITIONER SUCTION LINE
Weight
2 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| AC FITTING #280 SLPR EVAP OUT TUBE ASM 3/4 NOM OD | 1 | 4050725C1 |
| CAP, REFRIGERATOR FITTING .720" I.D. | 1 | 3570522C1 |
| O-RING SEAL 15 35/64" X 2 5/8" | 1 | 3543728C1 |
| SEAL, C- PLATE 3/4" | 1 | 3543882C1 |
| CAP REFRIGERANT FITTING 3/4" MALE | 1 | 3555227C1 |
| AC FITTING #267 EVAP SUCTION SHT SLPR 3/4 NOM OD | 1 | 4050727C1 |
| AC FITTING #131 EVAP OUT TXV TUBE ASM 5/8 NOM OD | 1 | 4050693C1 |
| RING ,O HNBR 12.93 ID X 1.86 THK | 1 | 1693970C1 |
CROSS REFERENCES
- JB HUNT 26738
- JB HUNT 26738
- PARKER 722056
- PARKER 722056
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
