446879001
COMPRESSOR, AIR W/SEALED CONNECTOR
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$1,249.95
$1,499.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
COMPRESSOR, AIR W/SEALED CONNECTOR
Weight
22.05 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| COMPRESSOR, AIR 10 AMP | 1 | 94703200 |
| PAD, AIR COMPRESSOR | 1 | 433070001 |
| COVER COMPRESSOR MOTOR | 1 | 433068001 |
| TERMINAL, RING 16/14 AWG | 2 | 203370000 |
| TAB, LOCK 2 CIRCUIT | 1 | 446715001 |
| CONTACT, RECEPTACLE 20-16 | 2 | 442609001 |
| TAB, LOCK PLATE 2 CIRCUIT | 1 | 446720001 |
| SEAL, WIRE 20-16 AWG | 2 | 442612001 |
| SWITCH, PRESSURE 80-100 PSI | 1 | 2221714C1 |
| SWITCH, PRESSURE 40-100 PSI | 1 | 95124300 |
| TRAY, COMPRESSOR | 1 | 433069001 |
| WASHER, SPLIT LOCK PLATED 3/16" | 3 | 91403200 |
| SCREW, PAN HEAD #8 X 3/4" | 3 | 26281R1 |
| FITTING, SOCKET HEAD PLUG 1/8" NPT | 1 | 444688 |
| FITTING, "T" BRASS 1/4" NPTF | 1 | 4490000 |
| CONNECTOR, TUBE 1/4" MPT X 3/8" | 1 | 30757VX |
| FITTING, HOSE QUICK CONNECT 1/4" NPT X 3/8" TUBE | 1 | 2017484C1 |
| CONNECTOR, TUBE 1/4" MPT X 3/8" | 1 | 30757V |
| FITTING, CLOSE NIPPLE BRASS 1/4" NPT | 2 | 4500000 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
