23537843
Fuel Pump to Cylinder Head Tube Assembly for S60 14L Air Compressor
Detroit Diesel
AVAILABLE
3 are currently available
Ships within 11-13 business days
$164.95
$197.94
This truck part is made by Detroit Diesel. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
This stainless steel tube assembly is tailored for the air compressor connection on S60 engines, featuring a wall thickness of 0.04 inches and a diameter of 0.37 inches. The fittings are threaded 11/16-16 inches, ensuring a tight, leak-proof fit to the compressor and cylinder head. The stainless steel construction provides excellent resistance to corrosion and temperature extremes, critical for maintaining consistent air pressure and compressor efficiency. Its zinc or aluminum finish adds an extra layer of protection against environmental wear. This tube assembly plays a vital role in delivering compressed air reliably to various engine systems, supporting optimal performance and longevity of the compressor unit. For quality assurance and expert support, Source One Parts Center supplies this essential component designed for heavy-duty industrial applications.
SPECIFICATIONS
Tube Wall Thickness
0.04 in
Tube 1 Outer Diameter
0.37 in
VMRS
065-008-002
End 1 Fitting Thread Size
11/16-16 in
End 2 Fitting Thread Size
11/16-16 in
OEM Part Number
DDE 23537843
Tube 1 Material
Stainless Steel
OEM Description
TUBE ASSEMBLY FUEL PUMP TO CYLINDER HEAD (1 CYLINDER AIR COMPRESSOR) S60
Finish
Zinc Or Aluminum
