R23534363
Turbo Assembly Vent 1.75 A/R High Mount .110 Ring
Detroit Diesel
AVAILABLE
1 is currently available
Ships within 11-13 business days
This truck part is made by Detroit Diesel. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
This VNT turbo assembly with a 1.75 A/R high mount configuration provides precise variable vane control for 12L engines. Its compact dimensions, including a 301.19 mm overall length and 11 mm mounting hole diameter, support easy installation. The inlet oil pressure at 30 psi and 20-micron filtration rating contribute to reliable lubrication and debris protection. The turbine and compressor components are engineered for maximum efficiency, with a turbine outlet diameter of 122.70 mm and compressor inlet of 129.03 mm. The unit operates at a maximum RPM of 2100, delivering responsive boost across engine loads. Its robust design ensures durability against thermal and mechanical stresses. For optimal performance and longevity, installation and calibration by experienced technicians at Source One Parts Center are recommended, helping you get the most from your turbo system.
SPECIFICATIONS
VMRS
043-004-001
Compressor Outlet Outer Diameter
107 mm
Mounting Hole Diameter
11 mm
Turbine Outlet Outer Diameter
122.70 mm
Compressor Inlet Outer Diameter
129.03 mm
Maximum Rated Revolutions Per Minute
1800 RPM
Micron Rating
20 microns
Inlet Oil Pressure
30 psi
Overall Length
301.19 mm
Compressor Outlet Inner Diameter
82.35 mm
Oil Inlet Inner Diameter
9.53 mm
OEM Part Number
DDE R23534363
Fuel Type
Diesel
OEM Description
TURBO ASSEMBLY VENT 1.75 A/R HIGH MOUNT .110 RING
CROSS REFERENCES
- DDE E23534363, E23534363, DDE-E23534363, DDEE23534363
