R23534362
Turbo Assembly Vent 1.75 A/R High Mount .110 Ring
Detroit Diesel
AVAILABLE
2 are currently available
Ships within 16-18 business days
This truck part is made by Detroit Diesel. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
This high-mount VNT turbo assembly features a 1.75 A/R ratio, engineered for 12L diesel engines requiring precise boost control. The overall length of approximately 301.19 mm and 11 mm mounting holes facilitate straightforward installation. The inlet oil pressure of 30 psi and micron rating of 20 ensure proper lubrication and filtration. Its dimensions support efficient exhaust and intake airflow, with a turbine outlet diameter of 122.70 mm. The compressor inlet diameter of 129.03 mm and outlet of 82.35 mm are designed for optimal air handling. Capable of operating at up to 2100 RPM, it delivers reliable performance in demanding conditions. Its durable construction withstands high-temperature exhaust gases and continuous use. For optimal results, professional installation assistance from Source One Parts Center is recommended, ensuring your engine achieves peak efficiency and power.
SPECIFICATIONS
VMRS
043-004-001
Compressor Outlet Outer Diameter
107 mm
Mounting Hole Diameter
11 mm
Turbine Outlet Outer Diameter
122.70 mm
Compressor Inlet Outer Diameter
129.03 mm
Micron Rating
20 microns
Maximum Rated Revolutions Per Minute
2100 RPM
Inlet Oil Pressure
30 psi
Overall Length
301.19 mm
Compressor Outlet Inner Diameter
82.35 mm
Oil Inlet Inner Diameter
9.53 mm
OEM Part Number
DDE R23534362
Fuel Type
Diesel
OEM Description
TURBO ASSEMBLY VENT 1.75 A/R HIGH MOUNT .110 RING
CROSS REFERENCES
- DDE E23534362, E23534362, DDE-E23534362, DDEE23534362
