R23528066
Turbo Assembly 1.28 A/R Vertical Low Mount for Series 60 12L
Detroit Diesel
AVAILABLE
1 is currently available
Ships within 11-13 business days
This truck part is made by Detroit Diesel. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
This turbo assembly is designed with a 1.28 A/R vertical low configuration, specifically for Series 60 engines with a 12L displacement. Its overall length of 301.44 mm supports installation in constrained engine compartments. The turbine features a 75.15 mm exducer diameter and an inducer of 82 mm, maximizing exhaust energy utilization. The compressor inlet diameter is 129.03 mm, with an outlet of 107 mm, supporting high airflow rates necessary for demanding diesel applications. The assembly includes a micron rating of 20 and is rated for up to 2100 RPM, ensuring durability and high performance. Its construction emphasizes thermal stability and mechanical resilience, critical for heavy-duty engine longevity. Source One Parts Center stocks this turbo to meet urgent maintenance and upgrade needs efficiently.
SPECIFICATIONS
VMRS
043-004-001
Compressor Outlet Outer Diameter
107 mm
Mounting Hole Diameter
11 mm
Turbine Outlet Inner Diameter
115.70 mm
Turbine Trim
12.98 mm
Turbine Outlet Outer Diameter
122.70 mm
Compressor Inlet Outer Diameter
129.03 mm
Micron Rating
20 microns
Maximum Rated Revolutions Per Minute
2100 RPM
Inlet Oil Pressure
30.01 psi
Overall Length
301.44 mm
Compressor Inducer Diameter
70.25 mm
Turbine Exducer Diameter
75.15 mm
Compressor Trim
8.83 mm
Turbine Inducer Diameter
82 mm
Compressor Outlet Inner Diameter
82.35 mm
Oil Inlet Inner Diameter
9.53 mm
Compressor Exducer Diameter
93.98 mm
OEM Part Number
DDE R23528066
Fuel Type
Diesel
OEM Description
TURBO ASSEMBLY 1.28 A/R VERT LOW S60 12L
CROSS REFERENCES
- DDE E23528066, E23528066, DDE-E23528066, DDEE23528066
