R23528065
Remanufactured Turbocharger for Series 60 EPA98 12L with Medium/High Mount
Detroit Diesel
AVAILABLE
More than 10 are currently available
Ships within 11-13 business days
This truck part is made by Detroit Diesel. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
This remanufactured turbocharger is tailored for Series 60 engines meeting EPA98 standards, with a 12L capacity and medium/high mount configuration. Its dimensions include a turbine outlet diameter of 122.71 mm and a compressor inlet of 129.03 mm, supporting high airflow and thermal efficiency. The unit is rated for a maximum RPM of 2100 and features a series designation of 60, with a capacity of 12 liters. Its construction emphasizes durability through remanufacturing processes, with high-quality components to ensure long service life. The design supports emissions compliance and optimized boost performance, crucial for heavy-duty applications. Source One Parts Center offers this turbocharger to facilitate reliable engine operation and efficient maintenance procedures.
SPECIFICATIONS
Compressor Trim
0.35 in
Compressor Adiabatic Ratio
0.60
VMRS
043-004-001
Turbine Adiabatic Ratio
1.28
Capacity
12 L
Turbine Trim
12.98 in
Engine Displacement
12700 cc
Compressor Inducer Diameter
2.77 in
Turbine Exducer Diameter
2.96 in
Maximum Rated Revolutions Per Minute
2100 RPM
Turbine Inducer Diameter
3.23 in
Compressor Exducer Diameter
3.70 in
Cylinder Quantity
6
Series
60
OEM Part Number
DDE R23528065
Fuel Type
Diesel
OEM Description
REMAN TURBOCHARGER, SERIES 60, EPA98, 12L, WG, GTA4294, MEDIUM / HIGH MOUNT
CROSS REFERENCES
- DDE R23528065NCW, R23528065NCW, DDE-R23528065NCW, DDER23528065NCW, ABP R01 23528065, R01 23528065, R01-23528065, R0123528065, ABP-R01-23528065, ABPR0123528065, DDE E23528065, E23528065, DDE-E23528065, DDEE23528065
