R23528031
Remanufactured Turbocharger Series 50 EPA98 8L GTA4294 ETR
Detroit Diesel
BACK ORDERED
Please contact us for information on lead time
This truck part is made by Detroit Diesel. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
This high-performance remanufactured turbocharger tailored for the Series 50 engine offers reliable boosting capabilities necessary for demanding trucking tasks. Its design features a GTA4294BDN model with a 0.91 A/R ratio, optimized for quick spool-up and sustained high RPM operation. The precise dimensions of the turbine and compressor housings ensure excellent airflow and minimal lag, directly translating to better throttle response and power delivery. Built to withstand the rigors of diesel operation, it incorporates durable materials and high-precision machining. The assembly’s length and mounting specifications facilitate straightforward installation, while its performance characteristics support maximum engine efficiency. For fleet operators seeking to restore or upgrade turbo performance, Source One Parts Center supplies authentic replacements and technical support to ensure maximum uptime and optimal engine operation.
SPECIFICATIONS
VMRS
043-004-001
Compressor Outlet Outer Diameter
107 mm
Mounting Hole Diameter
11 mm
Turbine Outlet Outer Diameter
122.70 mm
Compressor Inlet Outer Diameter
127 mm
Micron Rating
20 microns
Maximum Rated Revolutions Per Minute
2100 RPM
Overall Length
286.14 mm
Inlet Oil Pressure
30.01 psi
Turbine Exducer Diameter
75.23 mm
Turbine Inducer Diameter
82.04 mm
Compressor Outlet Inner Diameter
82.35 mm
Oil Inlet Inner Diameter
9.53 mm
OEM Part Number
DDE R23528031
Fuel Type
Diesel
OEM Description
REMAN TURBOCHARGER, SERIES 50, EPA98, 8L, WG, GTA4294, ETR
CROSS REFERENCES
- DDE E23528031, E23528031, DDE-E23528031, DDEE23528031
