E23534777
Turbocharger Series 60 EPA02 14L VNT GT4502V High Mount
Detroit Diesel
BACK ORDERED
Please contact us for information on lead time
This truck part is made by Detroit Diesel. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
This series 60 high-mount turbocharger incorporates a VNT system, designed to meet EPA 02 standards with a 14L engine. Its dimensions include a length of around 301 mm, with an 11 mm mounting hole diameter, ensuring compatibility with existing engine setups. The turbo features a 9.53 mm oil inlet inner diameter, facilitating proper lubrication, while the turbine outlet and compressor inlet/outlet sizes are optimized for efficient airflow. The turbine outlet diameter of 122.7 mm complements the compressor’s 102.26 mm exducer diameter, providing the boost necessary for demanding applications. Operating at a maximum of 2100 RPM, its construction prioritizes durability and thermal resistance, suitable for sustained heavy-duty use. The integrated VNT mechanism offers precise boost control, improving fuel economy and reducing emissions. Source One Parts Center offers this high-performance turbo, trusted for quality and reliability in diesel engine systems.
SPECIFICATIONS
VMRS
043-004-001
Compressor Outlet Outer Diameter
107 mm
Mounting Hole Diameter
11 mm
Turbine Outlet Inner Diameter
115.70 mm
Turbine Outlet Outer Diameter
122.70 mm
Compressor Inlet Outer Diameter
129.03 mm
Micron Rating
20 microns
Maximum Rated Revolutions Per Minute
2100 RPM
Inlet Oil Pressure
30.01 psi
Overall Length
301.44 mm
Compressor Outlet Inner Diameter
82.35 mm
Oil Inlet Inner Diameter
9.53 mm
OEM Part Number
DDE E23534777
Fuel Type
Diesel
OEM Description
TURBOCHARGER - SERIES 60, EPA02, 14L, VNT, GT4502V, HIGH MOUNT
CROSS REFERENCES
- DDE R23534777, R23534777, DDE-R23534777, DDER23534777
